Ethernet Network Test Solutions for Traffic Generation and Analysis

Protocol Analysis, Traffic Generation, Network Emulation, and Impairment solutions for high speed Ethernet and Terabit Solutions

Teledyne LeCroy’s Ethernet test solutions are designed to provide the tools needed to fully validate and bring new network products to market through:

Ethernet Protocol Analyzers
Ethernet Traffic Generations
Ethernet Error Injectors
Network Emulation
Network Impairment

SierraNet Ethernet Protocol Analyzer and Jammer

The SierraNet Family of Ethernet Analyzers and Jammers test platforms provide best in class Layer 1-7 traffic capture, analysis, and manipulation error injection for testing physical link characteristics and application operations for all layers of Ethernet. These products are designed to provide deep recording buffers to allow for easily capturing errors and simplifying the process for test, debug, and analysis. for address today’s high-speed storage and communications network problems and compliments other tools offering industry leading visibility and utility.

800G Ethernet Analyzer and Jammer

SierraNet M1288

50G to 800G
QSFP-DD and OSFP Support
Automated Auto-Negotiation and Link Training Testing

400G Ethernet Analyzer and Jammer

SierraNet M648

10G to 400G
SFP and QSFP-DD Support
Full line rate capture for both PAM4 and NRZ

100G Ethernet Analyzer and Jammer

SierraNet M328

10G to 100G
8 x SFP Ports
Capture and Error Injection for Ethernet Layers 1-7

100G Ethernet Analyzer and Jammer

SierraNet M328Q

10G to 100G
QSFP 4x25G
Automated test solution for analysis and jamming

100G Ethernet Analyzer

SierraNet T328

10G to 100G
8 x SFP Ports
TAP Probing technology for passive link capture

Xena Test Modules

Xena Ethernet traffic generation modules are divided into 5 groups based on the SerDes speeds they support up to 800Gbps. There is also a 100Gbps network emulation called Chimera. All include extensive Physical Layer test capabilities. Xena test modules can be mounted in one of the Xena Chassis (link to chassis below).

Ethernet Traffic Generator

Xena Z800 Freya

50G to 800G PAM4 testing
QSFP-DD800 and OSFP-800 supported
Drives optical transceivers and DACs

Ethernet Traffic Generator

Xena Z400 Thor

10G to 100G NRZ & 50G to 400G PAM4 data rates
Two transceiver cages
Auto-Neg & Link Training (AN/LT) interoperability

Ethernet Traffic Generator

Xena Z100 Loki

10G to 100G NRZ data rates
2-port dual media
Traffic Generation and Analysis

Ethernet Traffic Generator

Xena Z10 Odin

10M to 10G NRZ data rates
7 Odin traffic generators model options available
Traffic Generation and Analysis
Automotive T1 variant

Ethernet Network Emulation

Xena E100 Chimera

10G to 100G NRZ data rates
True wire-speed impairment
Impairments: latency/jitter, packet & port impairments, flexible distributions, BW shaping

Xena Chassis

Xena test modules can be mounted in either a modular 4U chassis with 12 slots for greater flexibility and scalability, or a 1U fixed single slot chassis that is easy to transport and suitable for desktop use.

4U 12-Slot Modular Chassis

Xena B720/B2400

High-density
Low power consumption per test port
Easy to use and cost effective

1U 1-Slot Chassis

Xena Compact

Advanced Architecture
Test automation with XOA
Easy to use and cost effective

Software

Xena Manager and Xena OpenAutomation (XOA) software are used to control the Xena chassis and test modules. LinkExpert is used to provide a fully automated test solution managing both SierraNet and Xena.

Automated Ethernet Auto Negotiation and Link Training Testing

LinkExpert for Ethernet

100G to 800G
Positive and Negative FEC
Fallback Speeds
Boundaries for coefficients

Ethernet Traffic Generation, Analysis, and Network Emulation

Xena Manager

Ethernet Traffic Generation & Physical Layer testing software
Test Ethernet speeds up to 800Gbps
Impair Ethernet traffic up to 100Gbps
Easy management of ports and traffic

Open-Source Test Automation Framework

Xena OpenAutomation

Python API that runs on any Operating System
Multiple Test Suite Desktop Applications
Easy converter to migrate Xena test suite into XOA
