モータ・ドライブ�アナライザ
MDA800Aシリーズ

モータ・ドライブ�アナライザは、モータ・ドライブ�入力から機械��力までの数値�三相解析結果の表示と、波形によるパワー解析を提供します。多様なセンサーに対応し、モータの速度、角度、トルクなどの機械��を読み取れます。ロングメモリを使ったサイクルごとのパラメータ値の時間変動グラフとZoom+Gateモードを使�、モータおよびモータ・ドライブ�動的解析が行えます�8チャンネルのアナログ入力��12ビット�高�解能、最�2.5GS/sのサンプリング速度、最�1GHzの帯域と最長250M ポイント�ロングメモリを提供し、モータ・ドライブ�パワーエレクトロニク ス部の解析、モータの機械�能評価、�みコントローラ動作検証を含む全てを網�るシス�の��を可能にします�


  •
  •
  •

主な特徴

  • モータ・ドライブ�シス�の完�な���価が一台の機器で可能
  • 三相パワー計測、実効電力、皮相電力、無効電力�計測
  • 効��
  • ユーザ・カスタマイズ可能なパワー計測値の一覧表示
  • 2電力計法およ�3電力計法をサポ��
  • パワー計測値からサイクル毎�時間変動プロ�を作�
  • サイクル毎�全高調波歪みの計測*
  • 表形式およ�グラフック表示による高調波解�*
  • 柔軟な高調波フィルタの適用*
  • スタートア��からオーバ�ロード�シャ�ダウンまでのダイナミ�・レスポンス解�
  • 独自のZoom+Gateモー�
  • 標準的なライン−ラインからライン−ニュートラルへの電圧変換表示
  • HVDシリーズ差動�ローブによる6000VRMSアイソレーション測�
  • 他社製電流計測�イスを使用する
    場合�容易なインタフェース
    • 完�なモータ��の取り込み
    (トルク、スピ�ド、�ジション��
    • フレキシブルなセ�ア��
    • グラフィカルな設定メニュー

完�なドライブ�シス�の��

モータ・ドライブ�アナライザはドライ ブ�パワー・セクション、パワー・トランジスタおよび�込み制御シス�の波形を捕捉、パワー・セクションの波形から三相パワー解析を実施出来、�とつの測定器で完�なモータ・ドライブ�全側面の解析と��を可能にします�

モータ・ ドライブ�全ての側面の解析や��が一台の機器で可能

�ダイン・レクロイのモータ・ドライブ�パワー解析ソリューションはパワーアナライザと� ての数値表示機�はもちろん、パワー値の時間変動と共に�回路の動作状態を並べて表 示することでモータ・ドライブ回路の挙動を把握し、異常動作�������為の 豊富な��を取得できます�

パワー計測値の一覧表示

様�電圧�流値��(実効電力、皮相電力、無効電力)、位相�/力率、およ�効�ラメータは捕捉された電圧�流波形から計算され、表形式で一覧表示できます。この��ブルは捕捉波形と同じ画面に表示されます�

Zoom+Gate動的解�

ロングメモリで捕捉した波形��タは、Zoom+Gateモードで、拡大したエリアのみのパラメータ計測を行い、またパラメータの変動グラフを作�することができます。拡大エリアを返納すると、それらの��も同時に変更される�で、強力な��・��ルとなり、不良解析に役立ちます�

モータの機械�ラメータの取り込み

アナログ/�タル(パルス)タコメータ �ラシレスDC(BLDC)ホ�ル・センサ、直交エンコーダ・インタフェース (QEI)、レゾルバを含む、ほぼどんな形式�スピ�ド、回転、あるいはポジショ ン・センサの値も平易に取り込む事が可能です。加えて、�ールセンサとQEI信号は�タル入力として取り込み、貴重なアナログ入力チャンネルを他�信号に振り�けることが�来ます�

サイクル毎�計測値の時間変動波形表示

��ブルに表示される平�に�えて、テーブル上�値をクリ�して選択するだけでサイクル毎��測値の時間変動グラフを表示することが可能です� こ�プロ�はモータ・ドライブ�アナライザにより捕捉された他�波形と時間相関を持ち、他�制御�ワー・シス�波形と�なドライブ動作との関連づけを行い、ドライブ�シス�の問題���に役 立ちます。計測値セ�の詳細統計情報も表示可能です。この追���は単体測定器としてのパワーアナライザで表示されるものを大きく凌駕します�

動的ドライブ�レスポンス

モータ・ドライブ�アナライザのロング波形メモリ(最大250Mポイン�/ch)は他�機器では実現できな�ータおよびドライブ�動的挙動の解析�力を提供します。例えばサンプリング・レー�10MS/sの設定では25秒間も�連続波形捕捉が可能になります。これによりスタートア����荷投�、急激な�荷変動に対する動的なドライブ挙動を完�に把握することが�来、ドライブ動作�問題と制御シス�動作もしくはパワー・セクションの不�合�関連づけをする事が可能です�

柔軟なセ�ア��

8つのアナログ入力チャンネルではドライブ�力あるいは出力どちらか一方側の三相の電圧�流信号の直接計測が可能です。しかしながら、三相電力�計測に2電力計法を適用できるため�2 つの電圧と電流信号の計測で三相計測が可能になります。これにより8つのアナログ入力チャンネルでもドライブ�完�な入出力�効�測が可能になります�

同様にライン−ラインからライン−ニュートラル電圧への変換もサポ�トし、直感的なライン−ライン・プロービングを行って�も各相ごとのライン−ニュートラルの結果を得ることができます�

センサ・アクイジション・モジュール SAM40

最大シス�構���48ch入� アナログ8ch �� �タル16ch �� 低速アナログ24ch

センサ・アクイジション・モジュール SAM40シリーズは、HDO8000Aまた�MDA800Aのアナログ入力�8ch)�デジタル入力�16ch�に、最大24chの低速アナログ入力�40MHz�100KS/s�を増設することが可能で、数多くのセンサの出力を24ビット���解能で捕捉し、本体と同期して表示および解析することができます�







ペ�ジトップへ

基本仕�
モ�� 帯� ch数 サンプリング速度
標準メモリ 垂直�能��
販売終�
MDA 803A
350MHz 8ch 2.5GS/s
50Mポイン�/ch 12ビッ�
販売終�
MDA 805A
500MHz 8ch
販売終�
MDA 810A
1GHz 8ch

* エンハンスド�サンプリング�� 10GS/s

スペック詳細 �モ�名をクリ�で詳細表示されます�

MDA803A スペック

Vertical - Analog Channels

Analog Bandwidth (Max) 350 MHz
Analog Bandwidth @ 50 Ω (-3 dB) (ProBus Input) 350 MHz
(≧1 mV/div)
Analog Bandwidth @ 1 MΩ (-3 dB) (ProBus Input) 350 MHz (typical)
Rise Time (10-90%, 50 Ω) 1 ns (typical)
Rise Time (20-80%, 50 Ω) 750 ps (typical)
Input Channels 8
Vertical Resolution 12 bits; up to 15 bits with enhanced resolution (ERES)
Effective Number of Bits (ENOB) 8.7 bits
Vertical Noise Floor (1 mV/div) 85 uVrms
Vertical Noise Floor (2 mV/div) 85 uVrms
Vertical Noise Floor (5 mV/div) 90 uVrms
Vertical Noise Floor (10 mV/div) 95 uVrms
Vertical Noise Floor (20 mV/div) 110 uVrms
Vertical Noise Floor (50 mV/div) 210 uVrms
Vertical Noise Floor (100 mV/div) 360 uVrms
Vertical Noise Floor (200 mV/div) 1.10 mVrms
Vertical Noise Floor (500 mV/div) 2.10 mVrms
Vertical Noise Floor (1 V/div) 3.70 mVrms
Sensitivity 50 Ω: 1 mV-1 V/div, fully variable;
1 MΩ: 1 mV-10 V/div, fully variable
DC Vertical Gain Accuracy (Gain Component of DC Accuracy) ±(0.5%) F.S, offset at 0 V
Channel-Channel Isolation DC-200 MHz: 60 dB (>1000:1),
200 MHz up to rated BW: 50 dB (>300:1),
(For any two input channels, same v/div settings, typical)
Offset Range 50 Ω
±1.6 V @ 1 mV - 4.95 mV/div
±4 V @ 5 mV - 9.9 mV/div
±8 V @ 10 mV - 19.8 mV/div
±10 V @ 20 mV - 1 V/div

1 MΩ
±1.6 V @ 1 mV - 4.95 mV/div
±4 V @ 5 mV - 9.9 mV/div
±8 V @ 10 mV - 19.8 mV/div
±16 V @ 20 mV - 100 mV/div
±80 V @ 102 mV - 198 mV/div
±160 V @ 200 mV - 1 V/div
±400 V @ 1.02 V - 10 V/div
DC Vertical Offset Accuracy ±(1.0% of offset setting + 0.5%FS + 0.02% of max offset + 1mV)
Maximum Input Voltage 50 Ω: 5 Vrms,
1 MΩ: 400 V max
(DC + Peak AC ≦ 10 kHz)
Input Coupling 1 MΩ: AC, DC, GND; 50 Ω: DC, GND
Input Impedance 1 MΩ ± 2.0% || 16 pF,
50 Ω ± 2.0%
Bandwidth Limiters 20MHz, 200MHz
Rescaling Length: meters, inches, feet, yards, miles; Mass: grams, slugs; Temperature: celsius, fahrenheit, kelvin; Angle: radian, arcdegr, arcmin, arcsec, cycles, revolutions, turns; Velocity: m/s, in/s, ft/s, yd/s, miles/s; Acceleration: m/s2, in/s2, ft/s2, g0; Volume: liters, cubic meters, cubic inches, cubic feet, cubic yards; Force (Weight): newton, grain, ounce, pound; Pressure: pascal, bar, atmosphere (technical), atmosphere (standard), torr, psi; Electrical: volts, amps, watts, volt-amperes, volt-amperes reactive, farad, coulomb, ohm, siemen, volt/meter, coulomb/m2, farad/meter, siemen/meter, power factor; Magnetic: weber, tesla, henry, amp/meter, henry/meter; Energy: joule, Btu, calorie; Rotating Machine: radian/second, frequency, revolution/second, revolution/minute, N·m, lb-ft, lb-in, oz-in, watt, horsepower; Other: %.


Horizontal - Analog Channels

Timebases Internal timebase common to 8 input channels; an external clock may be applied at the auxiliary input for acquisition of channels 1-4 (channels 5-8 disabled)
Acquisition Modes Real-time, Roll, Random Interleaved Sampling (RIS), Sequence
Time/Division Range 20 ps/div - 5 ks/div with standard memory (up to 10 ks/div with -L memory, 25 ks/div with -XL memory);
RIS available at ≦ 10 ns/div; Roll Mode available at ≧ 100 ms/div and ≦ 5 MS/s
Clock Accuracy +/-2.5ppm + 1.0ppm/year from calibration
Sample Clock Jitter up to 10ms Acquired Time Range:
280fsrms (Internal Timebase Reference)
Delta Time Measurement Accuracy \sqrt{2}*\sqrt{(\frac{Noise}{SlewRate})^2+(Sample Clock Jitter)^2) (RMS)+(clock accuracy*reading)(seconds)
Jitter Measurement Floor \sqrt{(\frac{Noise}{SlewRate})^2+(Sample Clock Jitter)^2\; seconds\; rms\; (TIE)}
Jitter Between Channels Analog Channels: 2psrms (TIE, typical)
Digital Channels: 350ps (maximum) between any two channels
Analog-Digital Channels: <5ns (maximum) between any analog and any digital channel
Channel-Channel Deskew Range ±9 x time/div. setting, 100 ms max., each channel
External Timebase Reference (Input) 10MHz +/-25ppm at 0 to 10dBm into 50 Ohms
External Timebase Reference (Output) 10MHz, 2.0 dBm +/-1.5 dBm, sinewave synchronized to reference being used (internal or external reference)
External Clock DC to 100 MHz; (50 Ω/1 MΩ), EXT BNC input, for acquisition of channels 1-4 (channels 5-8 disabled). Minimum rise time and amplitude requirements apply at low frequencies.


Acquisition - Analog Channels

Sample Rate (Single-shot) 10 GS/s on 8 Ch with Enhanced Sample Rate
Sample Rate (Repetitive) 125 GS/s for repetitive signals (20 ps/div to 10 ns/div)
Memory Length (4 Ch / 2 Ch / 1Ch)
(Number of Segments)
50M/50M/50M
(30,000)
Memory Length Options (4 Ch / 2 Ch / 1Ch)
(Number of Segments)
L- Option:
100M / 100M / 100M
(60,000)
XL - Option:
250M / 250M / 250M
(65,000)
Intersegment Time 1 µs
Averaging Summed averaging to 1 million sweeps; continuous averaging to 1 million sweeps
Enhanced Resolution (ERES) From 12.5 to 15 bits vertical resolution
Envelope (Extrema) Envelope, floor, or roof for up to 1 million sweeps
Interpolation Linear or Sin x/x (2 pt and 4 pt); 5 or 10 GS/s Enhanced Sample Rate defaults to 2pt or 4pt Sin x/x respectively


Vertical, Horizontal, Acquisition - Digital Channels

Maximum Input Frequency 250 MHz
Minimum Detectable Pulse Width 2 ns
Input Channels 16 Digital channels (with HDO8k-MSO option)
Input Impedance (Flying Leads) 100 kΩ || 5 pF
Input Dynamic Range ± 20V
Maximum Input Voltage ±30V Peak
Maximum Input Voltage Swing 400mV
Threshold Groupings Pod 2: D15 - D8, Pod 1: D7 - D0
Threshold Selections TTL, ECL, CMOS (2.5 V, 3.3 V, 5 V), PECL, LVDS or User Defined
Threshold Accuracy ±(3% of threshold setting + 100mV)
User Defined Threshold Range ±10 V in 20 mV steps
User Defined Hysteresis Range 100 mV to 1.4 V in 100 mV steps
Sample Rate 1.25 GS/s
Record Length Standard: 50 MS - 16 Channels
Optional -L: 100 MS - 16 Channels
Optional - XL: 125 MS - 16 Channels
Channel-to-Channel Skew 350 ps


Triggering System

Modes Normal, Auto, Single, and Stop
Sources Any input channel, Ext, Ext/10, or line; slope and level unique to each source (except line trigger)
Coupling DC, AC, HFRej, LFRej
Pre-trigger Delay 0-100% of memory size (adjustable in 1% increments of 100 ns)
Post-trigger Delay 0-10,000 Divisions in real time mode, limited at slower time/div settings or in roll mode
Hold-off From 2 ns up to 20 s or from 1 to 99,999,999 events
Trigger and Interpolator Jitter ≦ 4 psrms (typical)
<0.1 ps RMS (typical, software assisted)
Internal Trigger Level Range ±4.1 div from center (typical)
External Trigger Level Range Ext (±0.4 V); Ext/10 (±4 V)
Maximum Trigger Rate 1,000,000 waveforms/second (in Sequence Mode, up to 8 channels)
Trigger Sensitivity with Edge Trigger ProBus Inputs 2 div @ < 350 MHz
1 div @ < 200 MHz
0.9 div @ < 10 MHz
(DC, AC, and LFRej coupling, ≧ 2 mV/div, 50 Ω)
Trigger Sensitivity with Edge Trigger (Aux Input) 2 div @ < 350 MHz
1 div @ < 200 MHz
0.9 div @ < 10 MHz
(DC, AC, and LFRej coupling)
Max. Trigger Frequency, SMART Trigger 350MHz


Trigger Types

Edge Triggers when signal meets slope (positive, negative, or either) and level condition.
Width Triggers on positive or negative glitches with selectable widths.
minimum width 1.5ns, Maximum Width: 20s
Glitch Triggers on positive or negative glitches with selectable widths. minimum width 1.5ns, Maximum Width: 20s
Window Triggers when signal exits a window defined by adjustable thresholds
Pattern Logic combination (AND, NAND, OR, NOR) of up to 9 inputs (8 channels and external trigger input). Each source can be high, low, or don’t care. The High and Low level can be selected independently. Triggers at start or end of the pattern.
TV-Composite Video Triggers NTSC or PAL with selectable line and field; HDTV (720p, 1080i, 1080p) with selectable frame rate (50 or 60 Hz) and Line; or CUSTOM with selectable Fields (1-8), Lines (up to 2000), Frame Rates (25, 30, 50, or 60 Hz), Interlacing (1:1, 2:1, 4:1, 8:1), or Synch Pulse Slope (Positive or Negative).
Runt Trigger on positive or negative runts defined by two voltage limits and two time limits. Select between 1 ns and 20 ns.
Slew Rate Trigger on edge rates. Select limits for dV, dt, and slope. Select edge limits between 1 ns and 20 ns.
Interval Triggers on intervals selectable between 1 ns and 20 s.
Dropout Triggers if signal drops out for longer than selected time between 1 ns and 20 s.
Measurement Trigger Select from a large number of measurement parameters. Trigger on a measurement value with qualified limits.
Multi-Stage: Qualified (Timeout or State/Edge Qualified) Triggers on any input source only if a defined state or edge occurred on another input source. Delay between sources is selectable by time or events. (Note: event B pattern trigger cannot include analog channels).
Triggers with Exclusion Technology Glitch, Width, Interval, Runt, Slew Rate - Trigger on intermittent faults by specifying the expected behavior and triggering when that condition is not met
Multi-Stage: Qualified First In Sequence acquisition mode, triggers repeatably on event B only if a defined pattern, state, or edge (event A) is satisfied in the first segment of the acquisition. Holdoff between sources is selectable by time or events. (Note: event B pattern trigger cannot include analog channels).
TriggerScan A Trigger Trainer analyzes the waveforms, identifies normal behavior, and then sets up a large set of rare event smart trigger setups that target abnormal behavior. The trainer ‘learns� trigger setups based on slew rates, periods, amplitudes outside of a range and then applies them sequentially.


Low Speed Serial Protocol Trigger (Optional)

Supported Protocols I2C, SPI (SPI, SSPI, SIOP), UART-RS232, CAN1.1, CAN2.0, CAN FD, LIN, FlexRay, MIL-STD-1553, AudioBus (I2S, LJ, RJ, TDM), USB1.x/2.0


Measurement Tools

Measurement Functionality Display up to 12 measurement parameters together with statistics, including mean, minimum, maximum, standard deviation, and total number. Each occurrence of each parameter is measured and added to the statistics table. Histicons provide a fast, dynamic view of parameters and waveshape characteristics. Parameter math allows addition, subtraction, multiplication, or division of two different parameters. Parameter gates define the location for measurement on the source waveform. Parameter accept criteria define allowable values based on range setting or waveform state.
Measurement Parameters - Horizontal + Jitter Cycles (number of), Delay (from trigger, 50%), � Delay (50%), Duty Cycle (50%, @level), Edges (number of, @level), Fall Time (90-10, @levels), Frequency (50%, @level), Half Period (@level), Hold Time (@level), N Cycle Jitter (peak-peak), Number of Points, Period (50%, @level), � Period (@level), Phase (@level), Rise Time (10-90, @levels), Setup (@levels), Skew (@levels), Slew Rate (@levels), Time Interval Error (@level), Time (@level), � Time (@level), Width (50%, @level), � Width (@level), X(value)@max, X(value)@min
Measurement Parameters - Vertical Amplitude, Base, Level@X, Maximum, Mean, Median, Minimum, Peak-to-Peak, RMS, Std. Deviation, Top.
Measurement Parameters - Pulse Area, Base, Fall Time (90-10, 80-20, @levels), Overshoot (positive, negative), Rise Time (10-90, 80-20, @levels), Top, Width (50%)
Measurement Parameters - Statistical (on Histograms) Full Width (@ Half Max, @ %), Amplitude, Base, Peak @ Max Population, Maximum, Mean, Median, Minimum, Mode, Range, RMS, Std. Deviation, Top, X(value)@Peak, Peaks (number of), Percentile, Population (@bin, total)


Math Tools

Math Functionality Display up to 12 math functions traces (F1-F12). The easy-to-use graphical interface simplifies setup of up to two operations on each function trace, and function traces can be chained together to perform math-on-math.
Math Operators - Basic Math Average (summed), Average (continuous), Difference (-), Envelope, Floor, Invert (negate), Product (x), Ratio (/), Reciprocal, Rescale (with units), Roof, Sum (+).
Math Operators - Digital (incl. with MSO models/options) Digital AND, Digital DFlipFlop, Digital NAND, Digital NOR, Digital NOT, Digital OR, Digital XOR
Math Operators - Filters Enhanced resolution (to 15 bits vertical), Interpolate (cubic, quadratic, sinx/x), (SinX)/x.
Math Operators - Frequency Analysis FFT (power spectrum, magnitude, phase, power density, real, imaginary, magnitude squared), up to full record length. Select from Rectangular, VonHann, Hamming, FlatTop and Blackman Harris windows.
Math Operators - Functions Absolute value, Correlation (two waveforms), Derivative, Deskew (resample), Exp (base e), Exp (base 10), Integral, Invert (negate), Log (base e), Log (base 10), Reciprocal, Rescale (with units), Square, Square root, Zoom (identity).
Math Operators - Other Segment, Sparse


Measurement and Math Integration

Measurement and Math Integration Histograms to display statistical distributions of up to 2 billion measurement parameters. Trend (datalog) of up to 1 million measurement parameters. Track (display parameter vs. time, time-correlated to acquisitions) any parameter. Persistence histogram and persistence trace (mean, range, sigma)


Pass/Fail Testing

Pass/Fail Testing Display up to 8 pass/fail queries using a Single or Dual Parameter Comparison (compare All values, or Any value <. ≦, =, >, ≧, within limit ±� value or %) or Mask Test (pre-defined or user-defined mask, waveform All In, All Out, Any In, or Any Out conditions). Combine queries into a boolean expression to Pass or Fail IF "All True", "All False", "Any True", "Any False", or groups or "All" or "Any", with following THEN Save (waveforms), Stop, Alarm, (send) Pulse, Hardcopy (send email, save screen image, save to clipboard, send to printer), or (save) LabNotebook.


Three-phase Electrical and Mechanical Motor Drive Analysis Software

Setup Capability Measurement Locations: AC Input, DC Bus (Link), Drive Output, Mechanical Output.
Wiring Configurations: AC Input: 1-phase / 2-wire (1V1A); 1-phase / 3-wire (2V/2A); 3-phase / 3-wire (2V2A); 3-phase / 3-wire (3V3A); 3-phase / 4-wire (3V3A); None. DC Bus: 1-phase / 2-wire (1V1A); None. Drive Output: 1-phase / Half-Bridge (1V1A); 1-phase / Full-Bridge (1V1A); 3-phase / 3-wire (2V2A); 3-phase / 3-wire (3V3A); 3-phase / 4-wire (3V3A); None.
Harmonic Filter: Select either Full Spectrum or Fundamental only. With MDA800-HARMONICS option, also select Fundamental + N Harmonics or Range (maximum 50th harmonic in both cases).
Sync (per-cycle) Measurement Signal: Independently settable for AC Input, DC Bus, Drive Output and Mechanical Output. Low pass filter (LPF) cutoff settable from 20 Hz to 1 MHz. Hysteresis settable from 0-100% full amplitude. Source can be any input analog channel, memory trace, or math function.
Voltage Measurement Method: Line-Line or Line-Neutral (with L-L to L-N conversion supported).
Calculation Waveform Sources: Any input channel or stored memory trace.
Numerics Measurement Table Selections Voltage: RMS voltage, AC Voltage, DC Voltage, Peak Positive Voltage, Peak Negative Voltage, Peak-Peak Voltage, Voltage, Crest Factor, Voltage Total Harmonic Distortion (THD) (with the MDA800-HARMONICS option).
Current: RMS Current, AC Current, DC Current, Peak Positive Current, Peak Negative Current, Peak-Peak Current, Current, Crest Factor, Current Total Harmonic Distortion (THD) (with the MDA800-HARMONICS option).
Power, Efficiency, Other: Real, Apparent, and Reactive Power, Peak Positive Real Power, Peak Negative Real Power, Power Total Harmonic Distortion (THD) (with the MDA800-HARMONICS option), Power Factor, Phase Angle, Incremental Efficiency, Total Efficiency, Frequency.
Motor Mechanical + Other: Torque, Speed1, Speed2, Angle1, Angle 2 (as defined by sensor, or adjusted with Offset Angle setting), Mechanical Power, AC induction motor Slip.
Source Selections: Voltage: Va, Vb, Vc, Va-b, Vb-c, Vc-a, Vr, Vs, Vt, Vr-s, Vs-t, Vt-r, Ia, Ib, Ic, Ir, Is, It, Vbus, Ibus, Mechanical. Up to 10 rows (sources) and 12 columns (measurements) may be displayed in the table at any time. Source selections dependent on Wiring Configuration selections and Line-Line to Line-Neutral selections.
Motor Mechanical Interface Speed+Direction: Analog Tachometer (0-xVdc = speed), Digital Tachometer (x pulse/revolution = speed), Applied Voltage. Controlled Area Network (CAN) Serial Data (CANbus TDME option must be ordered separately), Hall Sensors (Angle Tracking Observer filter may be applied to this selection).
Speed+Direction+Position: Resolver, SinCos, KMZ60, Quadrature Encoder Interface (QEI) (A, B, and optional Z input), Angle Tracking Observer filter may be applied to all selections.
Torque: Analog 0-Vdc = Torque, Analog mV/V = Torque, Analog Frequency Modulated = Torque, Motor Constant K * Current = Torque, Controlled Area Network (CAN) Serial Data = Torque. Source is CAN message with embedded digital data (CANbus TDME option must be ordered separately).
Per-cycle "Synthesized" Waveforms and Statistics Waveforms: A time-correlated waveform of any per-cycle Numerics Table measurement parameter may be created and displayed anywhere on the grid. Up to 12 detailed per-cycle Waveforms may be displayed at one time.
Statistics: Detailed statistics on up to 12 per-cycle Numerics Table measurement parameters may be displayed at one time.
Harmonics Calculation Option (MDA800-HARMONICS) Fundamental Frequency Detection: Fixed Frequency Detection mode (for Line AC inputs only) or Varying Frequency Detection Mode (for Line AC inputs or Inverter PWM outputs).
Number of Harmonics Calculated: Up to 100 (Fixed Frequency) or up to 50 (Varying Frequency).
Harmonics Table and Spectral Waveforms: Display values by Harmonic Order for up to 9 quantities (Voltage, Current and Power) for any or all of three phases (limited to Voltage and Current in Fixed Frequency mode).
Units/Limits Selection: Select from either Amps/Volts/Watts, %, or dB. For Fixed Frequency, selection Limits file or create and assign custom limits file.
Zoom+Gate Mode Press "Zoom+Gate" button to create zooms of all voltage, current and mechanical signals (analog or digital) and simultaneously gate the Numerics and Statistics tables to the zoomed area. Displayed per-cycle "synthesized" Waveforms are simultaneously time-correlated to the zoomed area. Scroll through the full acquisition using Zoom position and ratio (size) controls and view instantaneous updates of table values.
Typical Accuracy Typically within 1%, depending on voltage and current measurement device.


Display System

Size Color 12.1" widescreen flat panel TFT-Active Matrix with high resolution touch screen
Resolution WXGA; 1280 x 800 pixels.
Number of traces Display a maximum of 40 traces. Simultaneously display channel, zoom, memory, math, and X-Y traces.
Grid Styles Auto, Single, Dual, Triplex, Quad, Octal, Tandem, Triad, Quattro, Twelve, Sixteen, Twenty, X-Y, Single+X-Y, Dual+X-Y, DualX-Y, TripleX-Y, QuattroX-Y, HexX-Y, OctalX-Y, DualX-YSingle, DualX-YDual, HexX-Ydual.
Supports Normal Display Mode (1 grid style, selectable) or Q-Scape Display Mode (4 different tabs, each with individually selectable grid styles). Q-Scape tabbed displays may be viewed in Single, Dual, or Mosaic mode.
Waveform Representation Sample dots joined, or sample dots only


Persistence Display

Analog and Color-Graded Persistence Variable saturation levels; stores each trace’s persistence data in memory
Persistence Types Select analog, color, or three-dimensional
Trace Selection Activate persistence on all or any combination of traces
Persistence Aging Select from 500 ms to infinity
Sweep Display Modes All accumulated, or all accumulated with last trace highlighted


Zoom Expansion Traces

Zoom Expansion Traces Display up to 12 Zoom and 12 Math/Zoom traces


Internal Waveform Memory

Internal Waveform Memory 12 active waveform memory traces (M1-M12) store 16 bit/point full length waveforms. Waveforms can be stored to any number of files limited only by the data storage media capacity.


Setup Storage

Front Panel and Instrument Status Store to the internal hard drive, over the network, or to a USB-connected peripheral device.


Automatic Setup

Auto Setup Automatically sets timebase, trigger, and sensitivity to display a wide range of repetitive signals
Find Vertical Scale Automatically sets the vertical sensitivity and offset for the selected channel to display a waveform with the maximum dynamic range


Calibration

Calibration Stability Calibration ensured within +/-5°C operating temperature. Manual calibration may be invoked if outside this temperature range.


Processor/CPU

Type Intel® CoreTM i7-4790S Quad, 3.2 GHz (4.0 GHz in turbo mode) (or better)
Processor Memory 16 GB standard for standard memory (50 Mpt) with 32 GB optional.
32 GB standard for -L and -XL memory options.
Operating System Microsoft Windows® 7 Pro 64 bit Embedded
Oscilloscope Operating Software Teledyne LeCroy MAUI with OneTouch
Real Time Clock Date and time displayed with waveform in hardcopy files. SNTP support to synchronize to precision internal clocks.


Connectivity

Ethernet Port Supports 2 10/100/1000BaseT Ethernet interface (RJ45 ports)
USB Host Ports Minimum 6 total: 2 front panel USB2.0 and 4 rear-mounted USB3.0 support Windows compatible devices
USB Device Port 1 USBTMC port
GPIB Port (optional) Supports IEEE - 488.2 (External)
External Monitor Port DisplayPort 1.2 compatible to support customer-supplied external monitor.
Includes support for extended desktop operation with UHD 3840 x 2160 pixel resolution and split-grid capability on external monitor.
Supports touch screen integration of external monitor (Note: external display can not use a Fujitsu touch-screen driver).
Remote Control Via Windows Automation, or via LeCroy Remote Command Set


Auxiliary Input

Signal Types Select External Trigger or External Clock Input on the front panel
Coupling 50 Ω: DC; 1 MΩ: AC, DC, GND
Max. Input Voltage 50 Ω: 5 Vrms; 1 MΩ: 400 Vmax (DC + Peak AC ≦ 5 kHz)


Auxiliary Output

Signal Types Select from control signals or Off
Output Signal 500 Hz-1 MHz square wave or DC level; 50 mV-1 V into 1 MΩ
Control Signals Trigger enabled, trigger out, pass/fail status, off
Connector Type BNC, located on rear panel


Probes

Probes Qty. (4) ÷10 Passive Probes
Probe System ProBus. Automatically detects and supports a variety of compatible probes
Scale Factors Automatically or manually selected depending on probe used
Calibration Output Default is 1kHz square wave, 1Vp-p (typical), output to probe hook. Settable from 250 Hz to 1 MHz square wave; 50 mV to 1.0V.


Power Requirements

Voltage 100-240 VAC ±10% at 45-66 Hz; 110-120 VAC ±10% at 380-420 Hz; Automatic AC Voltage Selection; Installation Category 300 V CAT II
Nominal Power Consumption 400 W / 400 VA
Max. Power Consumption 550 W / 550 VA (with all PC peripherals and active probes connected to 8 channels)


Environmental

Temperature (Operating) +5 °C to +40 °C
Temperature (Non-Operating) -20 °C to +60 °C
Humidity (Operating) 5% to 80% relative humidity (non-condensing) up to +31 °C.
Upper limit derates to 50% relative humidity (non-condensing) at +40 °C.
Humidity (Non-Operating) 5% to 95% relative humidity (non-condensing) as tested per MIL-PRF-28800F
Altitude (Operating) Up to 10,000 ft. (3048 m) at or below +30 °C
Altitude (Non-Operating) Up to 40,000 ft. (12,192 m)
Random Vibration (Operating) 0.31 grms 5 Hz to 500 Hz, 15 minutes in each of three orthogonal axes
Random Vibration (Non-Operating) 2.4 grms 5 Hz to 500 Hz, 15 minutes in each of three orthogonal axes
Functional Shock 30 g peak, half sine, 11 ms pulse, 3 shocks (positive and negative) in each of three orthogonal axes, 18 shocks total


Size and Weight

Dimensions (HWD) 14.8"H x 16.4"W x 11"D (375 mm x 416 mm x 280 mm)
Weight 26.8 lbs. (12.2 kg)
Shipping Weight 21.8 kg. (48 lbs.)


Certifications

CE Certification
UL and cUL Listing
CE Compliant, UL and cUL listed; conforms to
UL 61010-1 (3rd Edition), UL 61010-2-030 (1st Edition)
CAN/CSA C22.2 No. 61010-1-12


Warranty and Service

Warranty and Service 3-year warranty; calibration recommended annually.
Optional service programs include extended warranty, upgrades, and calibration services.

MDA805A スペック

Vertical - Analog Channels

Analog Bandwidth (Max) 500 MHz
Analog Bandwidth @ 50 Ω (-3 dB) (ProBus Input) 500 MHz
(≧1 mV/div)
Analog Bandwidth @ 1 MΩ (-3 dB) (ProBus Input) 500 MHz (typical)
Rise Time (10-90%, 50 Ω) 700 ps (typical)
Rise Time (20-80%, 50 Ω) 525 ps (typical)
Input Channels 8
Vertical Resolution 12 bits; up to 15 bits with enhanced resolution (ERES)
Effective Number of Bits (ENOB) 8.6 bits
Vertical Noise Floor (1 mV/div) 100 uVrms
Vertical Noise Floor (2 mV/div) 100 uVrms
Vertical Noise Floor (5 mV/div) 105 uVrms
Vertical Noise Floor (10 mV/div) 110 uVrms
Vertical Noise Floor (20 mV/div) 130 uVrms
Vertical Noise Floor (50 mV/div) 265 uVrms
Vertical Noise Floor (100 mV/div) 450 uVrms
Vertical Noise Floor (200 mV/div) 1.25 mVrms
Vertical Noise Floor (500 mV/div) 2.60 mVrms
Vertical Noise Floor (1 V/div) 4.50 mVrms
Sensitivity 50 Ω: 1 mV-1 V/div, fully variable;
1 MΩ: 1 mV-10 V/div, fully variable
DC Vertical Gain Accuracy (Gain Component of DC Accuracy) ±(0.5%) F.S, offset at 0 V
Channel-Channel Isolation DC-200 MHz: 60 dB (>1000:1),
200 MHz up to rated BW: 50 dB (>300:1),
(For any two input channels, same v/div settings, typical)
Offset Range 50 Ω
±1.6 V @ 1 mV - 4.95 mV/div
±4 V @ 5 mV - 9.9 mV/div
±8 V @ 10 mV - 19.8 mV/div
±10 V @ 20 mV - 1 V/div

1 MΩ
±1.6 V @ 1 mV - 4.95 mV/div
±4 V @ 5 mV - 9.9 mV/div
±8 V @ 10 mV - 19.8 mV/div
±16 V @ 20 mV - 100 mV/div
±80 V @ 102 mV - 198 mV/div
±160 V @ 200 mV - 1 V/div
±400 V @ 1.02 V - 10 V/div
DC Vertical Offset Accuracy ±(1.0% of offset setting + 0.5%FS + 0.02% of max offset + 1mV)
Maximum Input Voltage 50 Ω: 5 Vrms,
1 MΩ: 400 V max
(DC + Peak AC ≦ 10 kHz)
Input Coupling 1 MΩ: AC, DC, GND; 50 Ω: DC, GND
Input Impedance 1 MΩ ± 2.0% || 16 pF,
50 Ω ± 2.0%
Bandwidth Limiters 20MHz, 200MHz
Rescaling Length: meters, inches, feet, yards, miles; Mass: grams, slugs; Temperature: celsius, fahrenheit, kelvin; Angle: radian, arcdegr, arcmin, arcsec, cycles, revolutions, turns; Velocity: m/s, in/s, ft/s, yd/s, miles/s; Acceleration: m/s2, in/s2, ft/s2, g0; Volume: liters, cubic meters, cubic inches, cubic feet, cubic yards; Force (Weight): newton, grain, ounce, pound; Pressure: pascal, bar, atmosphere (technical), atmosphere (standard), torr, psi; Electrical: volts, amps, watts, volt-amperes, volt-amperes reactive, farad, coulomb, ohm, siemen, volt/meter, coulomb/m2, farad/meter, siemen/meter, power factor; Magnetic: weber, tesla, henry, amp/meter, henry/meter; Energy: joule, Btu, calorie; Rotating Machine: radian/second, frequency, revolution/second, revolution/minute, N·m, lb-ft, lb-in, oz-in, watt, horsepower; Other: %.


Horizontal - Analog Channels

Timebases Internal timebase common to 8 input channels; an external clock may be applied at the auxiliary input for acquisition of channels 1-4 (channels 5-8 disabled)
Acquisition Modes Real-time, Roll, Random Interleaved Sampling (RIS), Sequence
Time/Division Range 20 ps/div - 5 ks/div with standard memory (up to 10 ks/div with -L memory, 25 ks/div with -XL memory);
RIS available at ≦ 10 ns/div; Roll Mode available at ≧ 100 ms/div and ≦ 5 MS/s
Clock Accuracy +/-2.5ppm + 1.0ppm/year from calibration
Sample Clock Jitter up to 10ms Acquired Time Range:
280fsrms (Internal Timebase Reference)
Delta Time Measurement Accuracy \sqrt{2}*\sqrt{(\frac{Noise}{SlewRate})^2+(Sample Clock Jitter)^2) (RMS)+(clock accuracy*reading)(seconds)
Jitter Measurement Floor \sqrt{(\frac{Noise}{SlewRate})^2+(Sample Clock Jitter)^2\; seconds\; rms\; (TIE)}
Jitter Between Channels Analog Channels: 2psrms (TIE, typical)
Digital Channels: 350ps (maximum) between any two channels
Analog-Digital Channels: <5ns (maximum) between any analog and any digital channel
Channel-Channel Deskew Range ±9 x time/div. setting, 100 ms max., each channel
External Timebase Reference (Input) 10MHz +/-25ppm at 0 to 10dBm into 50 Ohms
External Timebase Reference (Output) 10MHz, 2.0 dBm +/-1.5 dBm, sinewave synchronized to reference being used (internal or external reference)
External Clock DC to 100 MHz; (50 Ω/1 MΩ), EXT BNC input, for acquisition of channels 1-4 (channels 5-8 disabled). Minimum rise time and amplitude requirements apply at low frequencies.


Acquisition - Analog Channels

Sample Rate (Single-shot) 10 GS/s on 8 Ch with Enhanced Sample Rate
Sample Rate (Repetitive) 125 GS/s for repetitive signals (20 ps/div to 10 ns/div)
Memory Length (4 Ch / 2 Ch / 1Ch)
(Number of Segments)
50M/50M/50M
(30,000)
Memory Length Options (4 Ch / 2 Ch / 1Ch)
(Number of Segments)
L- Option:
100M / 100M / 100M
(60,000)
XL - Option:
250M / 250M / 250M
(65,000)
Intersegment Time 1 µs
Averaging Summed averaging to 1 million sweeps; continuous averaging to 1 million sweeps
Enhanced Resolution (ERES) From 12.5 to 15 bits vertical resolution
Envelope (Extrema) Envelope, floor, or roof for up to 1 million sweeps
Interpolation Linear or Sin x/x (2 pt and 4 pt); 5 or 10 GS/s Enhanced Sample Rate defaults to 2pt or 4pt Sin x/x respectively


Vertical, Horizontal, Acquisition - Digital Channels

Maximum Input Frequency 250 MHz
Minimum Detectable Pulse Width 2 ns
Input Channels 16 Digital channels (with HDO8k-MSO option)
Input Impedance (Flying Leads) 100 kΩ || 5 pF
Input Dynamic Range ± 20V
Maximum Input Voltage ±30V Peak
Maximum Input Voltage Swing 400mV
Threshold Groupings Pod 2: D15 - D8, Pod 1: D7 - D0
Threshold Selections TTL, ECL, CMOS (2.5 V, 3.3 V, 5 V), PECL, LVDS or User Defined
Threshold Accuracy ±(3% of threshold setting + 100mV)
User Defined Threshold Range ±10 V in 20 mV steps
User Defined Hysteresis Range 100 mV to 1.4 V in 100 mV steps
Sample Rate 1.25 GS/s
Record Length Standard: 50 MS - 16 Channels
Optional -L: 100 MS - 16 Channels
Optional - XL: 125 MS - 16 Channels
Channel-to-Channel Skew 350 ps


Triggering System

Modes Normal, Auto, Single, and Stop
Sources Any input channel, Ext, Ext/10, or line; slope and level unique to each source (except line trigger)
Coupling DC, AC, HFRej, LFRej
Pre-trigger Delay 0-100% of memory size (adjustable in 1% increments of 100 ns)
Post-trigger Delay 0-10,000 Divisions in real time mode, limited at slower time/div settings or in roll mode
Hold-off From 2 ns up to 20 s or from 1 to 99,999,999 events
Trigger and Interpolator Jitter ≦ 3.5 psrms (typical)
<0.1 ps RMS (typical, software assisted)
Internal Trigger Level Range ±4.1 div from center (typical)
External Trigger Level Range Ext (±0.4 V); Ext/10 (±4 V)
Maximum Trigger Rate 1,000,000 waveforms/second (in Sequence Mode, up to 8 channels)
Trigger Sensitivity with Edge Trigger ProBus Inputs 2 div @ < 500 MHz
1.5 div @ < 250 MHz
1 div @ < 200 MHz
0.9 div @ < 10 MHz
(DC, AC, and LFRej coupling, ≧ 2 mV/div, 50 Ω)
Trigger Sensitivity with Edge Trigger (Aux Input) 2 div @ < 500 MHz
1.5 div @ < 250 MHz
1 div @ < 200 MHz
0.9 div @ < 10 MHz
(DC, AC, and LFRej coupling)
Max. Trigger Frequency, SMART Trigger 500MHz


Trigger Types

Edge Triggers when signal meets slope (positive, negative, or either) and level condition.
Width Triggers on positive or negative glitches with selectable widths.
minimum width 1.5ns, Maximum Width: 20s
Glitch Triggers on positive or negative glitches with selectable widths. minimum width 1.5ns, Maximum Width: 20s
Window Triggers when signal exits a window defined by adjustable thresholds
Pattern Logic combination (AND, NAND, OR, NOR) of up to 9 inputs (8 channels and external trigger input). Each source can be high, low, or don’t care. The High and Low level can be selected independently. Triggers at start or end of the pattern.
TV-Composite Video Triggers NTSC or PAL with selectable line and field; HDTV (720p, 1080i, 1080p) with selectable frame rate (50 or 60 Hz) and Line; or CUSTOM with selectable Fields (1-8), Lines (up to 2000), Frame Rates (25, 30, 50, or 60 Hz), Interlacing (1:1, 2:1, 4:1, 8:1), or Synch Pulse Slope (Positive or Negative).
Runt Trigger on positive or negative runts defined by two voltage limits and two time limits. Select between 1 ns and 20 ns.
Slew Rate Trigger on edge rates. Select limits for dV, dt, and slope. Select edge limits between 1 ns and 20 ns.
Interval Triggers on intervals selectable between 1 ns and 20 s.
Dropout Triggers if signal drops out for longer than selected time between 1 ns and 20 s.
Measurement Trigger Select from a large number of measurement parameters. Trigger on a measurement value with qualified limits.
Multi-Stage: Qualified (Timeout or State/Edge Qualified) Triggers on any input source only if a defined state or edge occurred on another input source. Delay between sources is selectable by time or events. (Note: event B pattern trigger cannot include analog channels).
Triggers with Exclusion Technology Glitch, Width, Interval, Runt, Slew Rate - Trigger on intermittent faults by specifying the expected behavior and triggering when that condition is not met
Multi-Stage: Qualified First In Sequence acquisition mode, triggers repeatably on event B only if a defined pattern, state, or edge (event A) is satisfied in the first segment of the acquisition. Holdoff between sources is selectable by time or events. (Note: event B pattern trigger cannot include analog channels).
TriggerScan A Trigger Trainer analyzes the waveforms, identifies normal behavior, and then sets up a large set of rare event smart trigger setups that target abnormal behavior. The trainer ‘learns� trigger setups based on slew rates, periods, amplitudes outside of a range and then applies them sequentially.


Low Speed Serial Protocol Trigger (Optional)

Supported Protocols I2C, SPI (SPI, SSPI, SIOP), UART-RS232, CAN1.1, CAN2.0, CAN FD, LIN, FlexRay, MIL-STD-1553, AudioBus (I2S, LJ, RJ, TDM), USB1.x/2.0


Measurement Tools

Measurement Functionality Display up to 12 measurement parameters together with statistics, including mean, minimum, maximum, standard deviation, and total number. Each occurrence of each parameter is measured and added to the statistics table. Histicons provide a fast, dynamic view of parameters and waveshape characteristics. Parameter math allows addition, subtraction, multiplication, or division of two different parameters. Parameter gates define the location for measurement on the source waveform. Parameter accept criteria define allowable values based on range setting or waveform state.
Measurement Parameters - Horizontal + Jitter Cycles (number of), Delay (from trigger, 50%), � Delay (50%), Duty Cycle (50%, @level), Edges (number of, @level), Fall Time (90-10, @levels), Frequency (50%, @level), Half Period (@level), Hold Time (@level), N Cycle Jitter (peak-peak), Number of Points, Period (50%, @level), � Period (@level), Phase (@level), Rise Time (10-90, @levels), Setup (@levels), Skew (@levels), Slew Rate (@levels), Time Interval Error (@level), Time (@level), � Time (@level), Width (50%, @level), � Width (@level), X(value)@max, X(value)@min
Measurement Parameters - Vertical Amplitude, Base, Level@X, Maximum, Mean, Median, Minimum, Peak-to-Peak, RMS, Std. Deviation, Top.
Measurement Parameters - Pulse Area, Base, Fall Time (90-10, 80-20, @levels), Overshoot (positive, negative), Rise Time (10-90, 80-20, @levels), Top, Width (50%)
Measurement Parameters - Statistical (on Histograms) Full Width (@ Half Max, @ %), Amplitude, Base, Peak @ Max Population, Maximum, Mean, Median, Minimum, Mode, Range, RMS, Std. Deviation, Top, X(value)@Peak, Peaks (number of), Percentile, Population (@bin, total)


Math Tools

Math Functionality Display up to 12 math functions traces (F1-F12). The easy-to-use graphical interface simplifies setup of up to two operations on each function trace, and function traces can be chained together to perform math-on-math.
Math Operators - Basic Math Average (summed), Average (continuous), Difference (-), Envelope, Floor, Invert (negate), Product (x), Ratio (/), Reciprocal, Rescale (with units), Roof, Sum (+).
Math Operators - Digital (incl. with MSO models/options) Digital AND, Digital DFlipFlop, Digital NAND, Digital NOR, Digital NOT, Digital OR, Digital XOR
Math Operators - Filters Enhanced resolution (to 15 bits vertical), Interpolate (cubic, quadratic, sinx/x), (SinX)/x.
Math Operators - Frequency Analysis FFT (power spectrum, magnitude, phase, power density, real, imaginary, magnitude squared), up to full record length. Select from Rectangular, VonHann, Hamming, FlatTop and Blackman Harris windows.
Math Operators - Functions Absolute value, Correlation (two waveforms), Derivative, Deskew (resample), Exp (base e), Exp (base 10), Integral, Invert (negate), Log (base e), Log (base 10), Reciprocal, Rescale (with units), Square, Square root, Zoom (identity).
Math Operators - Other Segment, Sparse


Measurement and Math Integration

Measurement and Math Integration Histograms to display statistical distributions of up to 2 billion measurement parameters. Trend (datalog) of up to 1 million measurement parameters. Track (display parameter vs. time, time-correlated to acquisitions) any parameter. Persistence histogram and persistence trace (mean, range, sigma)


Pass/Fail Testing

Pass/Fail Testing Display up to 8 pass/fail queries using a Single or Dual Parameter Comparison (compare All values, or Any value <. ≦, =, >, ≧, within limit ±� value or %) or Mask Test (pre-defined or user-defined mask, waveform All In, All Out, Any In, or Any Out conditions). Combine queries into a boolean expression to Pass or Fail IF "All True", "All False", "Any True", "Any False", or groups or "All" or "Any", with following THEN Save (waveforms), Stop, Alarm, (send) Pulse, Hardcopy (send email, save screen image, save to clipboard, send to printer), or (save) LabNotebook.


Three-phase Electrical and Mechanical Motor Drive Analysis Software

Setup Capability Measurement Locations: AC Input, DC Bus (Link), Drive Output, Mechanical Output.
Wiring Configurations: AC Input: 1-phase / 2-wire (1V1A); 1-phase / 3-wire (2V/2A); 3-phase / 3-wire (2V2A); 3-phase / 3-wire (3V3A); 3-phase / 4-wire (3V3A); None. DC Bus: 1-phase / 2-wire (1V1A); None. Drive Output: 1-phase / Half-Bridge (1V1A); 1-phase / Full-Bridge (1V1A); 3-phase / 3-wire (2V2A); 3-phase / 3-wire (3V3A); 3-phase / 4-wire (3V3A); None.
Harmonic Filter: Select either Full Spectrum or Fundamental only. With MDA800-HARMONICS option, also select Fundamental + N Harmonics or Range (maximum 50th harmonic in both cases).
Sync (per-cycle) Measurement Signal: Independently settable for AC Input, DC Bus, Drive Output and Mechanical Output. Low pass filter (LPF) cutoff settable from 20 Hz to 1 MHz. Hysteresis settable from 0-100% full amplitude. Source can be any input analog channel, memory trace, or math function.
Voltage Measurement Method: Line-Line or Line-Neutral (with L-L to L-N conversion supported).
Calculation Waveform Sources: Any input channel or stored memory trace.
Numerics Measurement Table Selections Voltage: RMS voltage, AC Voltage, DC Voltage, Peak Positive Voltage, Peak Negative Voltage, Peak-Peak Voltage, Voltage, Crest Factor, Voltage Total Harmonic Distortion (THD) (with the MDA800-HARMONICS option).
Current: RMS Current, AC Current, DC Current, Peak Positive Current, Peak Negative Current, Peak-Peak Current, Current, Crest Factor, Current Total Harmonic Distortion (THD) (with the MDA800-HARMONICS option).
Power, Efficiency, Other: Real, Apparent, and Reactive Power, Peak Positive Real Power, Peak Negative Real Power, Power Total Harmonic Distortion (THD) (with the MDA800-HARMONICS option), Power Factor, Phase Angle, Incremental Efficiency, Total Efficiency, Frequency.
Motor Mechanical + Other: Torque, Speed1, Speed2, Angle1, Angle 2 (as defined by sensor, or adjusted with Offset Angle setting), Mechanical Power, AC induction motor Slip.
Source Selections: Voltage: Va, Vb, Vc, Va-b, Vb-c, Vc-a, Vr, Vs, Vt, Vr-s, Vs-t, Vt-r, Ia, Ib, Ic, Ir, Is, It, Vbus, Ibus, Mechanical. Up to 10 rows (sources) and 12 columns (measurements) may be displayed in the table at any time. Source selections dependent on Wiring Configuration selections and Line-Line to Line-Neutral selections.
Motor Mechanical Interface Speed+Direction: Analog Tachometer (0-xVdc = speed), Digital Tachometer (x pulse/revolution = speed), Applied Voltage. Controlled Area Network (CAN) Serial Data (CANbus TDME option must be ordered separately), Hall Sensors (Angle Tracking Observer filter may be applied to this selection).
Speed+Direction+Position: Resolver, SinCos, KMZ60, Quadrature Encoder Interface (QEI) (A, B, and optional Z input), Angle Tracking Observer filter may be applied to all selections.
Torque: Analog 0-Vdc = Torque, Analog mV/V = Torque, Analog Frequency Modulated = Torque, Motor Constant K * Current = Torque, Controlled Area Network (CAN) Serial Data = Torque. Source is CAN message with embedded digital data (CANbus TDME option must be ordered separately).
Per-cycle "Synthesized" Waveforms and Statistics Waveforms: A time-correlated waveform of any per-cycle Numerics Table measurement parameter may be created and displayed anywhere on the grid. Up to 12 detailed per-cycle Waveforms may be displayed at one time.
Statistics: Detailed statistics on up to 12 per-cycle Numerics Table measurement parameters may be displayed at one time.
Harmonics Calculation Option (MDA800-HARMONICS) Fundamental Frequency Detection: Fixed Frequency Detection mode (for Line AC inputs only) or Varying Frequency Detection Mode (for Line AC inputs or Inverter PWM outputs).
Number of Harmonics Calculated: Up to 100 (Fixed Frequency) or up to 50 (Varying Frequency).
Harmonics Table and Spectral Waveforms: Display values by Harmonic Order for up to 9 quantities (Voltage, Current and Power) for any or all of three phases (limited to Voltage and Current in Fixed Frequency mode).
Units/Limits Selection: Select from either Amps/Volts/Watts, %, or dB. For Fixed Frequency, selection Limits file or create and assign custom limits file.
Zoom+Gate Mode Press "Zoom+Gate" button to create zooms of all voltage, current and mechanical signals (analog or digital) and simultaneously gate the Numerics and Statistics tables to the zoomed area. Displayed per-cycle "synthesized" Waveforms are simultaneously time-correlated to the zoomed area. Scroll through the full acquisition using Zoom position and ratio (size) controls and view instantaneous updates of table values.
Typical Accuracy Typically within 1%, depending on voltage and current measurement device.


Display System

Size Color 12.1" widescreen flat panel TFT-Active Matrix with high resolution touch screen
Resolution WXGA; 1280 x 800 pixels.
Number of traces Display a maximum of 40 traces. Simultaneously display channel, zoom, memory, math, and X-Y traces.
Grid Styles Auto, Single, Dual, Triplex, Quad, Octal, X-Y, Single+X-Y, Dual+X-Y, Tandem, Triad, Quattro, Twelve, Sixteen, Twenty, DualX-Y, TripleX-Y, QuattroX-Y, HexX-Y, OctalX-Y, DualX-YSingle, DualX-YDual, HexX-Ydual.
Supports Normal Display Mode (1 grid style, selectable) or Q-Scape Display Mode (4 different tabs, each with individually selectable grid styles). Q-Scape tabbed displays may be viewed in SIngle, Dual, or Mosaic mode.
Waveform Representation Sample dots joined, or sample dots only


Persistence Display

Analog and Color-Graded Persistence Variable saturation levels; stores each trace’s persistence data in memory
Persistence Types Select analog, color, or three-dimensional
Trace Selection Activate persistence on all or any combination of traces
Persistence Aging Select from 500 ms to infinity
Sweep Display Modes All accumulated, or all accumulated with last trace highlighted


Zoom Expansion Traces

Zoom Expansion Traces Display up to 12 Zoom and 12 Math/Zoom traces


Internal Waveform Memory

Internal Waveform Memory 12 active waveform memory traces (M1-M12) store 16 bit/point full length waveforms. Waveforms can be stored to any number of files limited only by the data storage media capacity.


Setup Storage

Front Panel and Instrument Status Store to the internal hard drive, over the network, or to a USB-connected peripheral device.


Automatic Setup

Auto Setup Automatically sets timebase, trigger, and sensitivity to display a wide range of repetitive signals
Find Vertical Scale Automatically sets the vertical sensitivity and offset for the selected channel to display a waveform with the maximum dynamic range


Calibration

Calibration Stability Calibration ensured within +/-5°C operating temperature. Manual calibration may be invoked if outside this temperature range.


Processor/CPU

Type Intel® CoreTM i7-4790S Quad, 3.2 GHz (4.0 GHz in turbo mode) (or better)
Processor Memory 16 GB standard for standard memory (50 Mpt) with 32 GB optional.
32 GB standard for -L and -XL memory options.
Operating System Microsoft Windows® 7 Pro 64 bit Embedded
Oscilloscope Operating Software Teledyne LeCroy MAUI™ with OneTouch
Real Time Clock Date and time displayed with waveform in hardcopy files. SNTP support to synchronize to precision internal clocks.


Connectivity

Ethernet Port Supports 2 10/100/1000BaseT Ethernet interface (RJ45 ports)
USB Host Ports Minimum 6 total: 2 front panel USB2.0 and 4 rear-mounted USB3.0 support Windows compatible devices
USB Device Port 1 USBTMC port
GPIB Port (optional) Supports IEEE - 488.2 (External)
External Monitor Port DisplayPort 1.2 compatible to support customer-supplied external monitor.
Includes support for extended desktop operation with UHD 3840 x 2160 pixel resolution and split-grid capability on external monitor.
Supports touch screen integration of external monitor (Note: external display can not use a Fujitsu touch-screen driver).
Remote Control Via Windows Automation, or via LeCroy Remote Command Set


Auxiliary Input

Signal Types Select External Trigger or External Clock Input on the front panel
Coupling 50 Ω: DC; 1 MΩ: AC, DC, GND
Max. Input Voltage 50 Ω: 5 Vrms; 1 MΩ: 400 Vmax (DC + Peak AC ≦ 5 kHz)


Auxiliary Output

Signal Types Select from control signals or Off
Output Signal 500 Hz-1 MHz square wave or DC level; 50 mV-1 V into 1 MΩ
Control Signals Trigger enabled, trigger out, pass/fail status, off
Connector Type BNC, located on rear panel


Probes

Probes Qty. (4) ÷10 Passive Probes
Probe System ProBus. Automatically detects and supports a variety of compatible probes
Scale Factors Automatically or manually selected depending on probe used
Calibration Output Default is 1kHz square wave, 1Vp-p (typical), output to probe hook. Settable from 250 Hz to 1 MHz square wave; 50 mV to 1.0V.


Power Requirements

Voltage 100-240 VAC ±10% at 45-66 Hz; 110-120 VAC ±10% at 380-420 Hz; Automatic AC Voltage Selection; Installation Category 300 V CAT II
Nominal Power Consumption 400 W / 400 VA
Max. Power Consumption 550 W / 550 VA (with all PC peripherals and active probes connected to 8 channels)


Environmental

Temperature (Operating) +5 °C to +40 °C
Temperature (Non-Operating) -20 °C to +60 °C
Humidity (Operating) 5% to 80% relative humidity (non-condensing) up to +31 °C.
Upper limit derates to 50% relative humidity (non-condensing) at +40 °C.
Humidity (Non-Operating) 5% to 95% relative humidity (non-condensing) as tested per MIL-PRF-28800F
Altitude (Operating) Up to 10,000 ft. (3048 m) at or below +30 °C
Altitude (Non-Operating) Up to 40,000 ft. (12,192 m)
Random Vibration (Operating) 0.31 grms 5 Hz to 500 Hz, 15 minutes in each of three orthogonal axes
Random Vibration (Non-Operating) 2.4 grms 5 Hz to 500 Hz, 15 minutes in each of three orthogonal axes
Functional Shock 30 g peak, half sine, 11 ms pulse, 3 shocks (positive and negative) in each of three orthogonal axes, 18 shocks total


Size and Weight

Dimensions (HWD) 14.8"H x 16.4"W x 11"D (375 mm x 416 mm x 280 mm)
Weight 12.2 kg. (26.8 lbs.)
Shipping Weight 21.8 kg. (48 lbs.)


Certifications

CE Certification
UL and cUL Listing
CE Compliant, UL and cUL listed; conforms to
UL 61010-1 (3rd Edition), UL 61010-2-030 (1st Edition)
CAN/CSA C22.2 No. 61010-1-12


Warranty and Service

Warranty and Service 3-year warranty; calibration recommended annually.
Optional service programs include extended warranty, upgrades, and calibration services.

MDA810A スペック

Vertical - Analog Channels

Analog Bandwidth (Max) 1 GHz
Analog Bandwidth @ 50 Ω (-3 dB) (ProBus Input) 1 GHz
(≧1 mV/div)
Analog Bandwidth @ 1 MΩ (-3 dB) (ProBus Input) 500 MHz (typical)
Rise Time (10-90%, 50 Ω) 450 ps (typical)
Rise Time (20-80%, 50 Ω) 340 ps (typical)
Input Channels 8
Vertical Resolution 12 bits; up to 15 bits with enhanced resolution (ERES)
Effective Number of Bits (ENOB) 8.4 bits
Vertical Noise Floor (1 mV/div) 145 uVrms
Vertical Noise Floor (2 mV/div) 145 uVrms
Vertical Noise Floor (5 mV/div) 150 uVrms
Vertical Noise Floor (10 mV/div) 155 uVrms
Vertical Noise Floor (20 mV/div) 185 uVrms
Vertical Noise Floor (50 mV/div) 275 uVrms
Vertical Noise Floor (100 mV/div) 500 uVrms
Vertical Noise Floor (200 mV/div) 1.75 mVrms
Vertical Noise Floor (500 mV/div) 2.75 mVrms
Vertical Noise Floor (1 V/div) 4.90 mVrms
Sensitivity 50 Ω: 1 mV-1 V/div, fully variable;
1 MΩ: 1 mV-10 V/div, fully variable
DC Vertical Gain Accuracy (Gain Component of DC Accuracy) ±(0.5%) F.S, offset at 0 V
Channel-Channel Isolation DC-200 MHz: 60 dB (>1000:1),
200-500 MHz: 50 dB (>300:1),
500 MHz up to rated bandwidth: 40 dB (>100:1)
(For any two input channels, same v/div settings, typical)
Offset Range 50 Ω
±1.6 V @ 1 mV - 4.95 mV/div
±4 V @ 5 mV - 9.9 mV/div
±8 V @ 10 mV - 19.8 mV/div
±10 V @ 20 mV - 1 V/div

1 MΩ
±1.6 V @ 1 mV - 4.95 mV/div
±4 V @ 5 mV - 9.9 mV/div
±8 V @ 10 mV - 19.8 mV/div
±16 V @ 20 mV - 100 mV/div
±80 V @ 102 mV - 198 mV/div
±160 V @ 200 mV - 1 V/div
±400 V @ 1.02 V - 10 V/div
DC Vertical Offset Accuracy ±(1.0% of offset setting + 0.5%FS + 0.02% of max offset + 1mV)
Maximum Input Voltage 50 Ω: 5 Vrms,
1 MΩ: 400 V max
(DC + Peak AC ≦ 10 kHz)
Input Coupling 1 MΩ: AC, DC, GND; 50 Ω: DC, GND
Input Impedance 1 MΩ ± 2.0% || 16 pF,
50 Ω ± 2.0%
Bandwidth Limiters 20MHz, 200MHz
Rescaling Length: meters, inches, feet, yards, miles; Mass: grams, slugs; Temperature: celsius, fahrenheit, kelvin; Angle: radian, arcdegr, arcmin, arcsec, cycles, revolutions, turns; Velocity: m/s, in/s, ft/s, yd/s, miles/s; Acceleration: m/s2, in/s2, ft/s2, g0; Volume: liters, cubic meters, cubic inches, cubic feet, cubic yards; Force (Weight): newton, grain, ounce, pound; Pressure: pascal, bar, atmosphere (technical), atmosphere (standard), torr, psi; Electrical: volts, amps, watts, volt-amperes, volt-amperes reactive, farad, coulomb, ohm, siemen, volt/meter, coulomb/m2, farad/meter, siemen/meter, power factor; Magnetic: weber, tesla, henry, amp/meter, henry/meter; Energy: joule, Btu, calorie; Rotating Machine: radian/second, frequency, revolution/second, revolution/minute, N·m, lb-ft, lb-in, oz-in, watt, horsepower; Other: %.


Horizontal - Analog Channels

Timebases Internal timebase common to 8 input channels; an external clock may be applied at the auxiliary input for acquisition of channels 1-4 (channels 5-8 disabled)
Acquisition Modes Real-time, Roll, Random Interleaved Sampling (RIS), Sequence
Time/Division Range 20 ps/div - 5 ks/div with standard memory (up to 10 ks/div with -L memory, 25 ks/div with -XL memory);
RIS available at ≦ 10 ns/div; Roll Mode available at ≧ 100 ms/div and ≦ 5 MS/s
Clock Accuracy +/-2.5ppm + 1.0ppm/year from calibration
Sample Clock Jitter up to 10ms Acquired Time Range:
280fsrms (Internal Timebase Reference)
Delta Time Measurement Accuracy \sqrt{2}*\sqrt{(\frac{Noise}{SlewRate})^2+(Sample Clock Jitter)^2) (RMS)+(clock accuracy*reading)(seconds)
Jitter Measurement Floor \sqrt{(\frac{Noise}{SlewRate})^2+(Sample Clock Jitter)^2\; seconds\; rms\; (TIE)}
Jitter Between Channels Analog Channels: 2psrms (TIE, typical)
Digital Channels: 350ps (maximum) between any two channels
Analog-Digital Channels: <5ns (maximum) between any analog and any digital channel
Channel-Channel Deskew Range ±9 x time/div. setting, 100 ms max., each channel
External Timebase Reference (Input) 10MHz +/-25ppm at 0 to 10dBm into 50 Ohms
External Timebase Reference (Output) 10MHz, 2.0 dBm +/-1.5 dBm, sinewave synchronized to reference being used (internal or external reference)
External Clock DC to 100 MHz; (50 Ω/1 MΩ), EXT BNC input, for acquisition of channels 1-4 (channels 5-8 disabled). Minimum rise time and amplitude requirements apply at low frequencies.


Acquisition - Analog Channels

Sample Rate (Single-shot) 10 GS/s on 8 Ch with Enhanced Sample Rate
Sample Rate (Repetitive) 125 GS/s for repetitive signals (20 ps/div to 10 ns/div)
Memory Length (4 Ch / 2 Ch / 1Ch)
(Number of Segments)
50M/50M/50M
(30,000)
Memory Length Options (4 Ch / 2 Ch / 1Ch)
(Number of Segments)
L- Option:
100M / 100M / 100M
(60,000)
XL - Option:
250M / 250M / 250M
(65,000)
Intersegment Time 1 µs
Averaging Summed averaging to 1 million sweeps; continuous averaging to 1 million sweeps
Enhanced Resolution (ERES) From 12.5 to 15 bits vertical resolution
Envelope (Extrema) Envelope, floor, or roof for up to 1 million sweeps
Interpolation Linear or Sin x/x (2 pt and 4 pt); 5 or 10 GS/s Enhanced Sample Rate defaults to 2pt or 4pt Sin x/x respectively


Vertical, Horizontal, Acquisition - Digital Channels

Maximum Input Frequency 250 MHz
Minimum Detectable Pulse Width 2 ns
Input Channels 16 Digital channels (with HDO8k-MSO option)
Input Impedance (Flying Leads) 100 kΩ || 5 pF
Input Dynamic Range ± 20V
Maximum Input Voltage ±30V Peak
Maximum Input Voltage Swing 400mV
Threshold Groupings Pod 2: D15 - D8, Pod 1: D7 - D0
Threshold Selections TTL, ECL, CMOS (2.5 V, 3.3 V, 5 V), PECL, LVDS or User Defined
Threshold Accuracy ±(3% of threshold setting + 100mV)
User Defined Threshold Range ±10 V in 20 mV steps
User Defined Hysteresis Range 100 mV to 1.4 V in 100 mV steps
Sample Rate 1.25 GS/s
Record Length Standard: 50 MS - 16 Channels
Optional -L: 100 MS - 16 Channels
Optional - XL: 125 MS - 16 Channels
Channel-to-Channel Skew 350 ps


Triggering System

Modes Normal, Auto, Single, and Stop
Sources Any input channel, Ext, Ext/10, or line; slope and level unique to each source (except line trigger)
Coupling DC, AC, HFRej, LFRej
Pre-trigger Delay 0-100% of memory size (adjustable in 1% increments of 100 ns)
Post-trigger Delay 0-10,000 Divisions in real time mode, limited at slower time/div settings or in roll mode
Hold-off From 2 ns up to 20 s or from 1 to 99,999,999 events
Trigger and Interpolator Jitter ≦ 3.5 psrms (typical)
<0.1 ps RMS (typical, software assisted)
Internal Trigger Level Range ±4.1 div from center (typical)
External Trigger Level Range Ext (±0.4 V); Ext/10 (±4 V)
Maximum Trigger Rate 1,000,000 waveforms/second (in Sequence Mode, up to 8 channels)
Trigger Sensitivity with Edge Trigger ProBus Inputs 2 div @ < 1 GHz
1.5 div @ < 500 MHz
1 div @ < 200 MHz
0.9 div @ < 10 MHz
(DC, AC, and LFRej coupling, ≧ 2 mV/div, 50 Ω)
Trigger Sensitivity with Edge Trigger (Aux Input) 2 div @ < 1 GHz
1.5 div @ < 500 MHz
1 div @ < 200 MHz
0.9 div @ < 10 MHz
(DC, AC, and LFRej coupling)
Max. Trigger Frequency, SMART Trigger 1GHz


Trigger Types

Edge Triggers when signal meets slope (positive, negative, or either) and level condition.
Width Triggers on positive or negative glitches with selectable widths.
minimum width 1.5ns, Maximum Width: 20s
Glitch Triggers on positive or negative glitches with selectable widths. minimum width 1.5ns, Maximum Width: 20s
Window Triggers when signal exits a window defined by adjustable thresholds
Pattern Logic combination (AND, NAND, OR, NOR) of up to 9 inputs (8 channels and external trigger input). Each source can be high, low, or don’t care. The High and Low level can be selected independently. Triggers at start or end of the pattern.
TV-Composite Video Triggers NTSC or PAL with selectable line and field; HDTV (720p, 1080i, 1080p) with selectable frame rate (50 or 60 Hz) and Line; or CUSTOM with selectable Fields (1-8), Lines (up to 2000), Frame Rates (25, 30, 50, or 60 Hz), Interlacing (1:1, 2:1, 4:1, 8:1), or Synch Pulse Slope (Positive or Negative).
Runt Trigger on positive or negative runts defined by two voltage limits and two time limits. Select between 1 ns and 20 ns.
Slew Rate Trigger on edge rates. Select limits for dV, dt, and slope. Select edge limits between 1 ns and 20 ns.
Interval Triggers on intervals selectable between 1 ns and 20 s.
Dropout Triggers if signal drops out for longer than selected time between 1 ns and 20 s.
Measurement Trigger Select from a large number of measurement parameters. Trigger on a measurement value with qualified limits.
Multi-Stage: Qualified (Timeout or State/Edge Qualified) Triggers on any input source only if a defined state or edge occurred on another input source. Delay between sources is selectable by time or events. (Note: event B pattern trigger cannot include analog channels).
Triggers with Exclusion Technology Glitch, Width, Interval, Runt, Slew Rate - Trigger on intermittent faults by specifying the expected behavior and triggering when that condition is not met
Multi-Stage: Qualified First In Sequence acquisition mode, triggers repeatably on event B only if a defined pattern, state, or edge (event A) is satisfied in the first segment of the acquisition. Holdoff between sources is selectable by time or events. (Note: event B pattern trigger cannot include analog channels).
TriggerScan A Trigger Trainer analyzes the waveforms, identifies normal behavior, and then sets up a large set of rare event smart trigger setups that target abnormal behavior. The trainer ‘learns� trigger setups based on slew rates, periods, amplitudes outside of a range and then applies them sequentially.


Low Speed Serial Protocol Trigger (Optional)

Supported Protocols I2C, SPI (SPI, SSPI, SIOP), UART-RS232, CAN1.1, CAN2.0, CAN FD, LIN, FlexRay, MIL-STD-1553, AudioBus (I2S, LJ, RJ, TDM), USB1.x/2.0


Measurement Tools

Measurement Functionality Display up to 12 measurement parameters together with statistics, including mean, minimum, maximum, standard deviation, and total number. Each occurrence of each parameter is measured and added to the statistics table. Histicons provide a fast, dynamic view of parameters and waveshape characteristics. Parameter math allows addition, subtraction, multiplication, or division of two different parameters. Parameter gates define the location for measurement on the source waveform. Parameter accept criteria define allowable values based on range setting or waveform state.
Measurement Parameters - Horizontal + Jitter Cycles (number of), Delay (from trigger, 50%), � Delay (50%), Duty Cycle (50%, @level), Edges (number of, @level), Fall Time (90-10, @levels), Frequency (50%, @level), Half Period (@level), Hold Time (@level), N Cycle Jitter (peak-peak), Number of Points, Period (50%, @level), � Period (@level), Phase (@level), Rise Time (10-90, @levels), Setup (@levels), Skew (@levels), Slew Rate (@levels), Time Interval Error (@level), Time (@level), � Time (@level), Width (50%, @level), � Width (@level), X(value)@max, X(value)@min
Measurement Parameters - Vertical Amplitude, Base, Level@X, Maximum, Mean, Median, Minimum, Peak-to-Peak, RMS, Std. Deviation, Top.
Measurement Parameters - Pulse Area, Base, Fall Time (90-10, 80-20, @levels), Overshoot (positive, negative), Rise Time (10-90, 80-20, @levels), Top, Width (50%)
Measurement Parameters - Statistical (on Histograms) Full Width (@ Half Max, @ %), Amplitude, Base, Peak @ Max Population, Maximum, Mean, Median, Minimum, Mode, Range, RMS, Std. Deviation, Top, X(value)@Peak, Peaks (number of), Percentile, Population (@bin, total)


Math Tools

Math Functionality Display up to 12 math functions traces (F1-F12). The easy-to-use graphical interface simplifies setup of up to two operations on each function trace, and function traces can be chained together to perform math-on-math.
Math Operators - Basic Math Average (summed), Average (continuous), Difference (-), Envelope, Floor, Invert (negate), Product (x), Ratio (/), Reciprocal, Rescale (with units), Roof, Sum (+).
Math Operators - Digital (incl. with MSO models/options) Digital AND, Digital DFlipFlop, Digital NAND, Digital NOR, Digital NOT, Digital OR, Digital XOR
Math Operators - Filters Enhanced resolution (to 15 bits vertical), Interpolate (cubic, quadratic, sinx/x), (SinX)/x.
Math Operators - Frequency Analysis FFT (power spectrum, magnitude, phase, power density, real, imaginary, magnitude squared), up to full record length. Select from Rectangular, VonHann, Hamming, FlatTop and Blackman Harris windows.
Math Operators - Functions Absolute value, Correlation (two waveforms), Derivative, Deskew (resample), Exp (base e), Exp (base 10), Integral, Invert (negate), Log (base e), Log (base 10), Reciprocal, Rescale (with units), Square, Square root, Zoom (identity).
Math Operators - Other Segment, Sparse


Measurement and Math Integration

Measurement and Math Integration Histograms to display statistical distributions of up to 2 billion measurement parameters. Trend (datalog) of up to 1 million measurement parameters. Track (display parameter vs. time, time-correlated to acquisitions) any parameter. Persistence histogram and persistence trace (mean, range, sigma)


Pass/Fail Testing

Pass/Fail Testing Display up to 8 pass/fail queries using a Single or Dual Parameter Comparison (compare All values, or Any value <. ≦, =, >, ≧, within limit ±� value or %) or Mask Test (pre-defined or user-defined mask, waveform All In, All Out, Any In, or Any Out conditions). Combine queries into a boolean expression to Pass or Fail IF "All True", "All False", "Any True", "Any False", or groups or "All" or "Any", with following THEN Save (waveforms), Stop, Alarm, (send) Pulse, Hardcopy (send email, save screen image, save to clipboard, send to printer), or (save) LabNotebook.


Three-phase Electrical and Mechanical Motor Drive Analysis Software

Setup Capability Measurement Locations: AC Input, DC Bus (Link), Drive Output, Mechanical Output.
Wiring Configurations: AC Input: 1-phase / 2-wire (1V1A); 1-phase / 3-wire (2V/2A); 3-phase / 3-wire (2V2A); 3-phase / 3-wire (3V3A); 3-phase / 4-wire (3V3A); None. DC Bus: 1-phase / 2-wire (1V1A); None. Drive Output: 1-phase / Half-Bridge (1V1A); 1-phase / Full-Bridge (1V1A); 3-phase / 3-wire (2V2A); 3-phase / 3-wire (3V3A); 3-phase / 4-wire (3V3A); None.
Harmonic Filter: Select either Full Spectrum or Fundamental only. With MDA800-HARMONICS option, also select Fundamental + N Harmonics or Range (maximum 50th harmonic in both cases).
Sync (per-cycle) Measurement Signal: Independently settable for AC Input, DC Bus, Drive Output and Mechanical Output. Low pass filter (LPF) cutoff settable from 20 Hz to 1 MHz. Hysteresis settable from 0-100% full amplitude. Source can be any input analog channel, memory trace, or math function.
Voltage Measurement Method: Line-Line or Line-Neutral (with L-L to L-N conversion supported).
Calculation Waveform Sources: Any input channel or stored memory trace.
Numerics Measurement Table Selections Voltage: RMS voltage, AC Voltage, DC Voltage, Peak Positive Voltage, Peak Negative Voltage, Peak-Peak Voltage, Voltage, Crest Factor, Voltage Total Harmonic Distortion (THD) (with the MDA800-HARMONICS option).
Current: RMS Current, AC Current, DC Current, Peak Positive Current, Peak Negative Current, Peak-Peak Current, Current, Crest Factor, Current Total Harmonic Distortion (THD) (with the MDA800-HARMONICS option).
Power, Efficiency, Other: Real, Apparent, and Reactive Power, Peak Positive Real Power, Peak Negative Real Power, Power Total Harmonic Distortion (THD) (with the MDA800-HARMONICS option), Power Factor, Phase Angle, Incremental Efficiency, Total Efficiency, Frequency.
Motor Mechanical + Other: Torque, Speed1, Speed2, Angle1, Angle 2 (as defined by sensor, or adjusted with Offset Angle setting), Mechanical Power, AC induction motor Slip.
Source Selections: Voltage: Va, Vb, Vc, Va-b, Vb-c, Vc-a, Vr, Vs, Vt, Vr-s, Vs-t, Vt-r, Ia, Ib, Ic, Ir, Is, It, Vbus, Ibus, Mechanical. Up to 10 rows (sources) and 12 columns (measurements) may be displayed in the table at any time. Source selections dependent on Wiring Configuration selections and Line-Line to Line-Neutral selections.
Motor Mechanical Interface Speed+Direction: Analog Tachometer (0-xVdc = speed), Digital Tachometer (x pulse/revolution = speed), Applied Voltage. Controlled Area Network (CAN) Serial Data (CANbus TDME option must be ordered separately), Hall Sensors (Angle Tracking Observer filter may be applied to this selection).
Speed+Direction+Position: Resolver, SinCos, KMZ60, Quadrature Encoder Interface (QEI) (A, B, and optional Z input), Angle Tracking Observer filter may be applied to all selections.
Torque: Analog 0-Vdc = Torque, Analog mV/V = Torque, Analog Frequency Modulated = Torque, Motor Constant K * Current = Torque, Controlled Area Network (CAN) Serial Data = Torque. Source is CAN message with embedded digital data (CANbus TDME option must be ordered separately).
Per-cycle "Synthesized" Waveforms and Statistics Waveforms: A time-correlated waveform of any per-cycle Numerics Table measurement parameter may be created and displayed anywhere on the grid. Up to 12 detailed per-cycle Waveforms may be displayed at one time.
Statistics: Detailed statistics on up to 12 per-cycle Numerics Table measurement parameters may be displayed at one time.
Harmonics Calculation Option (MDA800-HARMONICS) Fundamental Frequency Detection: Fixed Frequency Detection mode (for Line AC inputs only) or Varying Frequency Detection Mode (for Line AC inputs or Inverter PWM outputs).
Number of Harmonics Calculated: Up to 100 (Fixed Frequency) or up to 50 (Varying Frequency).
Harmonics Table and Spectral Waveforms: Display values by Harmonic Order for up to 9 quantities (Voltage, Current and Power) for any or all of three phases (limited to Voltage and Current in Fixed Frequency mode).
Units/Limits Selection: Select from either Amps/Volts/Watts, %, or dB. For Fixed Frequency, selection Limits file or create and assign custom limits file.
Zoom+Gate Mode Press "Zoom+Gate" button to create zooms of all voltage, current and mechanical signals (analog or digital) and simultaneously gate the Numerics and Statistics tables to the zoomed area. Displayed per-cycle "synthesized" Waveforms are simultaneously time-correlated to the zoomed area. Scroll through the full acquisition using Zoom position and ratio (size) controls and view instantaneous updates of table values.
Typical Accuracy Typically within 1%, depending on voltage and current measurement device.


Display System

Size Color 12.1" widescreen flat panel TFT-Active Matrix with high resolution touch screen
Resolution WXGA; 1280 x 800 pixels.
Number of traces Display a maximum of 40 traces. Simultaneously display channel, zoom, memory, math, and X-Y traces.
Grid Styles Auto, Single, Dual, Triplex, Quad, Octal, X-Y, Single+X-Y, Dual+X-Y, Tandem, Triad, Quattro, Twelve, Sixteen, Twenty, DualX-Y, TripleX-Y, QuattroX-Y, HexX-Y, OctalX-Y, DualX-YSingle, DualX-YDual, HexX-Ydual.
Supports Normal Display Mode (1 grid style, selectable) or Q-Scape Display Mode (4 different tabs, each with individually selectable grid styles). Q-Scape tabbed displays may be viewed in SIngle, Dual, or Mosaic mode.
Waveform Representation Sample dots joined, or sample dots only


Persistence Display

Analog and Color-Graded Persistence Variable saturation levels; stores each trace’s persistence data in memory
Persistence Types Select analog, color, or three-dimensional
Trace Selection Activate persistence on all or any combination of traces
Persistence Aging Select from 500 ms to infinity
Sweep Display Modes All accumulated, or all accumulated with last trace highlighted


Zoom Expansion Traces

Zoom Expansion Traces Display up to 12 Zoom and 12 Math/Zoom traces


Internal Waveform Memory

Internal Waveform Memory 12 active waveform memory traces (M1-M12) store 16 bit/point full length waveforms. Waveforms can be stored to any number of files limited only by the data storage media capacity.


Setup Storage

Front Panel and Instrument Status Store to the internal hard drive, over the network, or to a USB-connected peripheral device.


Automatic Setup

Auto Setup Automatically sets timebase, trigger, and sensitivity to display a wide range of repetitive signals
Find Vertical Scale Automatically sets the vertical sensitivity and offset for the selected channel to display a waveform with the maximum dynamic range


Calibration

Calibration Stability Calibration ensured within +/-5°C operating temperature. Manual calibration may be invoked if outside this temperature range.


Processor/CPU

Type Intel® CoreTM i7-4790S Quad, 3.2 GHz (4.0 GHz in turbo mode) (or better)
Processor Memory 16 GB standard for standard memory (50 Mpt) with 32 GB optional.
32 GB standard for -L and -XL memory options.
Operating System Microsoft Windows® 7 Pro 64 bit Embedded
Oscilloscope Operating Software Teledyne LeCroy MAUI™ with OneTouch
Real Time Clock Date and time displayed with waveform in hardcopy files. SNTP support to synchronize to precision internal clocks.


Connectivity

Ethernet Port Supports 2 10/100/1000BaseT Ethernet interface (RJ45 ports)
USB Host Ports Minimum 6 total: 2 front panel USB2.0 and 4 rear-mounted USB3.0 support Windows compatible devices
USB Device Port 1 USBTMC port
GPIB Port (optional) Supports IEEE - 488.2 (External)
External Monitor Port DisplayPort 1.2 compatible to support customer-supplied external monitor.
Includes support for extended desktop operation with UHD 3840 x 2160 pixel resolution and split-grid capability on external monitor.
Supports touch screen integration of external monitor (Note: external display can not use a Fujitsu touch-screen driver).
Remote Control Via Windows Automation, or via LeCroy Remote Command Set


Auxiliary Input

Signal Types Select External Trigger or External Clock Input on the front panel
Coupling 50 Ω: DC; 1 MΩ: AC, DC, GND
Max. Input Voltage 50 Ω: 5 Vrms; 1 MΩ: 400 Vmax (DC + Peak AC ≦ 5 kHz)


Auxiliary Output

Signal Types Select from control signals or Off
Output Signal 500 Hz-1 MHz square wave or DC level; 50 mV-1 V into 1 MΩ
Control Signals Trigger enabled, trigger out, pass/fail status, off
Connector Type BNC, located on rear panel


Probes

Probes Qty. (4) ÷10 Passive Probes
Probe System ProBus. Automatically detects and supports a variety of compatible probes
Scale Factors Automatically or manually selected depending on probe used
Calibration Output Default is 1kHz square wave, 1Vp-p (typical), output to probe hook. Settable from 250 Hz to 1 MHz square wave; 50 mV to 1.0V.


Power Requirements

Voltage 100-240 VAC ±10% at 45-66 Hz; 110-120 VAC ±10% at 380-420 Hz; Automatic AC Voltage Selection; Installation Category 300 V CAT II
Nominal Power Consumption 400 W / 400 VA
Max. Power Consumption 550 W / 550 VA (with all PC peripherals and active probes connected to 8 channels)


Environmental

Temperature (Operating) +5 °C to +40 °C
Temperature (Non-Operating) -20 °C to +60 °C
Humidity (Operating) 5% to 80% relative humidity (non-condensing) up to +31 °C.
Upper limit derates to 50% relative humidity (non-condensing) at +40 °C.
Humidity (Non-Operating) 5% to 95% relative humidity (non-condensing) as tested per MIL-PRF-28800F
Altitude (Operating) Up to 10,000 ft. (3048 m) at or below +30 °C
Altitude (Non-Operating) Up to 40,000 ft. (12,192 m)
Random Vibration (Operating) 0.31 grms 5 Hz to 500 Hz, 15 minutes in each of three orthogonal axes
Random Vibration (Non-Operating) 2.4 grms 5 Hz to 500 Hz, 15 minutes in each of three orthogonal axes
Functional Shock 30 g peak, half sine, 11 ms pulse, 3 shocks (positive and negative) in each of three orthogonal axes, 18 shocks total


Size and Weight

Dimensions (HWD) 14.8"H x 16.4"W x 11"D (375 mm x 416 mm x 280 mm)
Weight 12.2 kg. (26.8 lbs.)
Shipping Weight 21.8 kg. (48 lbs.)


Certifications

CE Certification
UL and cUL Listing
CE Compliant, UL and cUL listed; conforms to
UL 61010-1 (3rd Edition), UL 61010-2-030 (1st Edition)
CAN/CSA C22.2 No. 61010-1-12


Warranty and Service

Warranty and Service 3-year warranty; calibration recommended annually.
Optional service programs include extended warranty, upgrades, and calibration services.


ペ�ジトップに戻�

クリ�で詳細表示されま�

センサ・アクイジション・モジュール

ミックスド�シグナル・ソリューション

メモリオプション

Computer Upgrade

リモート�コントロール/ネットワーク・オプション

電源解�

Serial Data Compliance

トリガ�デコード�パッケージ

ジ�解析パ�ージ

�タル・フィルタ・パッケージ

そ��

ペ�ジトップに戻�

クリ�で詳細表示されま�

プローブ�アダプタ

アク�ブ�プロー�

電流�ロー�

高精度差動アン�

差動�ロー�

高圧差動�ロー�

高圧プロー�

パッシブ�プロー�

アクセサリ・キ�

ペ�ジトップに戻�

パワー・アナライザ性能

Setup Capability

Measurement LocationsAC Input, DC Bus (Link), Drive Output, Mechanical Output
Wiring ConfigurationsAC Input: 1-phase / 2-wire (1V1A); 1-phase / 3-wire (2V/2A); 3-phase / 3-wire (2V2A); 3-phase / 3-wire (3V3A); 3-phase / 4-wire (3V3A); None
DC Bus: 1-phase / 2-wire (1V1A); None
Drive Output: 1-phase / Half-Bridge (1V1A); 1-phase / Full-Bridge (1V1A); 3-phase / 3-wire (2V2A); 3-phase / 3-wire (3V3A); 3-phase / 4-wire (3V3A); None
Harmonic FilterSelect either Full Spectrum or Fundamental only. With MDA800-HARMONICS option, also select Fundamental + N Harmonics or Range (maximum 50th harmonic in both cases).
Sync (per-cycle) Measurement SignalIndependently settable for AC Input, DC Bus, Drive Output and Mechanical Output.
Low pass filter (LPF) cutoff settable from 20 Hz to 1 MHz. Hysteresis settable from 0-100% full amplitude.
Source can be any input analog channel, memory trace, or math function.
Voltage Measurement MethodLine-Line or Line-Neutral (with L-L to L-N conversion supported)
Calculation Waveform SourcesAny input channel or stored memory trace


Numerics Measurement Table Selections (Per-cycle Calculated, Mean Value Displayed)

VoltageRMS voltage, AC Voltage, DC Voltage, Peak Positive Voltage, Peak Negative Voltage, Peak-Peak Voltage, Voltage Crest Factor, Voltage Total Harmonic Distortion (THD) (with the MDA800-HARMONICS option)
CurrentRMS Current, AC Current, DC Current, Peak Positive Current, Peak Negative Current, Peak-Peak Current, Current Crest Factor, Current Total Harmonic Distortion (THD) (with the MDA800-HARMONICS option)
Power, Efficiency, and OtherReal, Apparent, and Reactive Power, Peak Positive Real Power, Peak Negative Real Power, Power Total Harmonic Distortion (THD) (with the MDA800-HARMONICS option), Power Factor, Phase Angle, Incremental Efficiency, Total Efficiency, Frequency
Motor Mechanical + OtherTorque, Speed1, Speed2, Angle1, Angle 2 (as defined by sensor, or adjusted with Offset Angle setting), Mechanical Power, AC induction motor Slip
Source SelectionsVoltage: Va, Vb, Vc, Va-b, Vb-c, Vc-a, Vr, Vs, Vt, Vr-s, Vs-t, Vt-r, Ia, Ib, Ic, Ir, Is, It, Vbus, Ibus, Mechanical.
Up to 10 rows (sources) and 12 columns (measurements) may be displayed in the table at any time. Source selections dependent on Wiring Configuration selections and Line-Line to Line-Neutral selections.


Motor Mechanical Interface

Speed + DirectionAnalog Tachometer (0-xVdc = speed). Source is analog input.
Digital Tachometer (x pulse/revolution = speed). Source may be digital or analog input.
Applied Voltage. Source is one analog input.
Controlled Area Network (CAN) Serial Data. Source is CAN message with embedded digital data. CANbus TDM or TDME option must be ordered separately.
Hall Sensors (three digital inputs). Source may be digital or analog input. Angle Tracking Observer filter may be applied to this selection.
Speed + Direction + PositionResolver. Source is three analog inputs.
SinCos. Source is two analog inputs.
KMZ60. Source is two analog inputs.
Quadrature Encoder Interface (QEI) (A, B, and optional Z input). Source may be digital or analog input.
Angle Tracking Observer filter may be applied to all selections.
TorqueAnalog 0-Vdc = Torque. Source is one analog input.
Analog mV/V = Torque. Source is one analog input.
Analog Frequency Modulated = Torque. Source is one analog input.
Motor Constant K * Current = Torque. Source is MDA calculated per-cycle current value.
Controlled Area Network (CAN) Serial Data = Torque. Source is CAN message with embedded digital data. CANbus TDM or TDME option must be ordered separately.


Per-cycle "Synthesized" Waveforms and Statistics

WaveformsA time-correlated waveform of any per-cycle Numerics Table measurement parameter may be created and displayed anywhere on the grid. Up to 12 detailed per-cycle Waveforms may be displayed at one time, with up to 40 waveforms total (channels, memories, zooms, math, and per-cycle Waveforms) displayed at any one time.
StatisticsDetailed statistics on up to 12 per-cycle Numerics Table measurement parameters may be displayed at one time.


Harmonics Calculation Option (part number MDA800-HARMONICS)

Fundamental Frequency DetectionFixed Frequency Detection mode (for Line AC inputs only) or Varying Frequency Detection Mode (for Line AC inputs or Inverter PWM outputs).
Number of Harmonics CalculatedUp to 100 (Fixed Frequency) or up to 50 (Varying Frequency)
Harmonics Table and Spectral Waveform DisplayDisplay values by Harmonic Order for up to 9 quantities (Voltage, Current and Power) for any or all of three phases (limited to Voltage and Current in Fixed Frequency mode).
Units/Limits SelectionSelect from either Amps/Volts/Watts, %, or dB.
For Fixed Frequency, selection Limits file or create and assign custom limits file.


Zoom+Gate Mode

OperationPress "Zoom+Gate" button to create zooms of all voltage, current and mechanical signals (analog or digital) and simultaneously gate the Numerics and Statistics tables to the zoomed area. Displayed per-cycle "synthesized" Waveforms are simultaneously time-correlated to the zoomed area. Scroll through the full acquisition using Zoom position and ratio (size) controls and view instantaneous updates of table values.


Typical Accuracy

Voltage, Current and PowerTypically within 1%, depending on voltage and current measurement device.
Recommended voltage probe (line-line voltage sensing) = Teledyne LeCroy HVD Series High Voltage Differential Probe (1kV, 2kV and 6kV isolated models available).
Recommended voltage probe (line-neutral or line-reference voltage sensing) = Teledyne LeCroy HVD Series HV Differential Probe for voltages >50Vrms, Teledyne LeCroy passive probe (Qty. 4 included) for voltages <=50Vrms
Recommended current probes = Teledyne LeCroy CP Series Current Probes
Other voltage and current measurement devices may be interfaced to the oscilloscope and analysis software using built-in rescaling and unit selection capabilities. The CA10 current adapter provides programmability for rescaling and unit selection.


Available Options & Accessories

Acquisition Memory100 Mpt/ch (HDO8k-L) and 250 Mpt/ch (HDO8k-XL)
Mixed Signal OptionHDO8k-MSO: 16 digital logic channel acquisition at up to 250 MHz digital clock rate, flexible analog and digital cross-pattern trigger and use of digital logic lines for mechanical speed sensing and serial data clock, data, and chip select probing, including (optional) serial data triggers and decoding
Serial Triggers and DecodersA wide variety are available including I2C, SPI, UART-RS232, CAN, LIN, FlexRay, ARINC429, Audio (I2S), DPHY, DigRF3G, DigRFv4, ENET, Manchester, MIL1553, SENT, USB2, and USB2-HSIC. Symbolic triggering and decoding is available for CAN. ProtoBus MAG Serial Debug Tookit provides automatic serial message timing measurements and serial (digital) data extraction and conversion (D-A capability).
Probes and AccessoriesA comprehensive list of voltage and current probes is supported on the Motor Drive Analyzer. Additionally, rackmounts, carts, soft carrying cases and local language front panel overlays are also available.
Software OptionsInclude Power (Semiconductor Device) Analysis, Digital Filtering, Jitter, EMC/EMI Measurements, and Developer's Toolkit.

Consult HDO8000A datasheet for complete list of available options, accessories, and probes

ペ�ジトップに戻�
