WaveSurfer 4000HD High Definition Oscilloscopes

WaveSurfer 4000HD High Definition Oscilloscopes

WaveSurfer 4000HD extends Teledyne LeCroy’s leadership in High Definition Oscilloscopes with a bright, 12.1” touch screen display, performance without compromise, and price points that fit your budget.

Explore WaveSurfer 4000HD High Definition Oscilloscopes arrow down
  • product line tab
  • overview tab
  • options tab
  • options tab
  • probes tab
WaveSurfer 4024HD   (200 MHz Bandwidth, 4 Input Channels, 12.5 Mpts/ch, 5 GS/s)
Quick Specs
Sample Rate2.5 GS/s on 4Ch
Maximum Acquisition Memory25 Mpts (2 Ch operation)
Input Channels4
Vertical Resolution12-bits
WaveSurfer 4034HD   (350 MHz Bandwidth, 4 Input Channels, 12.5 Mpts/ch, 5 GS/s)
Quick Specs
Sample Rate2.5 GS/s on 4Ch
Maximum Acquisition Memory25 Mpts (2 Ch operation)
Input Channels4
Vertical Resolution12-bits
WaveSurfer 4054HD   (500 MHz Bandwidth, 4 Input Channels, 12.5 Mpts/ch, 5 GS/s)
Quick Specs
Sample Rate2.5 GS/s on 4Ch
Maximum Acquisition Memory25 Mpts (2 Ch operation)
Input Channels4
Vertical Resolution12-bits
WaveSurfer 4104HD   (1 GHz Bandwidth, 4 Input Channels, 12.5 Mpts/ch, 5 GS/s)
Quick Specs
Sample Rate2.5 GS/s on 4Ch
Maximum Acquisition Memory25 Mpts (2 Ch operation)
Input Channels4
Vertical Resolution12-bits
Check up to three models.
Key Features
  • Highest resolution – 12 bits all the time
  • More capability – integrates multiple instruments into one
  • Comprehensive probe support – supports over 30 probes in 9 categories
  • MAUI with OneTouch user interface for intuitive and efficient operation



HD4096 – 12 Bits All the Time, 16 x Closer to Perfect

Teledyne LeCroy high definition 12-bit oscilloscopes use unique HD4096 technology to provide superior and uncompromised measurement performance. HD4096 technology provides the highest resolution and lowest noise at full bandwidth—12 bits all the time with no compromise.



More Capability Than You Imagined

A suite of options for power, serial bus and embedded systems debug

  • Multi-instrument options
  • Serial trigger and decode software
  • Spectrum & power analysis software



Comprehensive Probe Support

Over 30 probes in 9 categories

  • Active power rail probes
  • Current probes
  • High-Voltage differential and fiber optic probes
  • TekProbe adapters



MAUI with OneTouch
  • Most unique touch screen features on any oscilloscope
  • Drag-and-drop to dramatically reduce setup time
  • All common operations can be performed with one touch



Main Specifications
Bandwidth 200 MHz - 1 GHz
Input Channels 4
Max Sampling Rate 5 GS/s
Resolution 12-bit
Starting from $9,100
Memory 25 Mpts
Max Memory 25 Mpts


Mixed Signal Option

WS4KHD-MSO
Mixed Signal Option for WaveSurfer 4000HD (includes probe, accessories, and license)

Remote Control/Network Options

USB2-GPIB
External USB 2.0 to GPIB IEEE 488.2 adapter

Power Analysis Software

WS4KHD-PWR
Power Analysis Option for WaveSurfer 4000HD

Serial Trigger and Decode

WS4KHD-AUDIO TD
AudioBus trigger and decode option for WaveSurfer 4000HD
WS4KHD-AUTO TD
Automotive SW bundle (CAN, CAN FD, LIN & FlexRay) for WaveSurfer 4000HD
WS4KHD-EMB TD
Embedded SW bundle (I2C, SPI, UART/RS232) for WaveSurfer 4000HD

Other Software Options

WS4kHD-SPECTRUM-1
Spectrum Analyzer for WaveSurfer 4000HD - 1 trace
WS4KHD-FG
Function Generator for WaveSurfer 4000HD

Miscellaneous

WS4KHD-SOFTCASE
WaveSurfer 4000HD Softcase
WS4KHD-RACK
WaveSurfer 4000HD Rackmount kit

High Voltage Fiber Optically-isolated Probes

HVFO108
High Voltage Fiber Optic Probe, 150 MHz Bandwidth. Includes soft-carrying case. Requires attenuating tip (ordered separately). Includes Qty. 1 1m Fiber Optic Cable.
HVFO100-1X-TIP-U
HVFO10X +/-1V (1x Attenuation) Universal Tip Accessory
HVFO100-5X-TIP-U
HVFO10X +/-5V (5x Attenuation) Universal Tip Accessory
HVFO100-10X-TIP-U
HVFO10X +/-10V (10x Attenuation) Universal Tip Accessory
HVFO100-20X-TIP-U
HVFO10X +/-20V (20x Attenuation) Universal Tip Accessory
HVFO100-40X-TIP-U
HVFO10X +/-40V (40x Attenuation) Universal Tip Accessory

Probe Adapters

TPA10
TekProbe to ProBus Probe Adapter

Active Voltage Rail Probe

RP2060
Power/Voltage Rail Probe. 2 GHz bandwidth, 1.2x attenuation, +/-60V offset, +/-800mV Includes a complete set of solder-in leads and coaxial cables. Browser tip sold seperately
RP4030
Power/Voltage Rail Probe. 4 GHz bandwidth, 1.2x attenuation, +/-30V offset, +/-800mV Includes a complete set of solder-in leads, coaxial cables, and PCB mounts. Limited Availability
RP4060
Power/Voltage Rail Probe. 4 GHz bandwidth, 1.2x attenuation, +/-60V offset, +/-800mV Includes a complete set of solder-in leads and coaxial cables. Browser tip sold seperately
RP4000-BROWSER
RP2060/RP4060 Browser Tip accessory. Includes 0 Ohm (1x), 450 Ohm (10x) and 950 Ohm (20x) tips.

Active Voltage Probes

ZS1000
1 GHz, 0.9 pF, 1 MOhm Active Voltage Probe
ZS1500
1.5 GHz, 0.9 pF, 1 MOhm Active Voltage Probe

Current Probes

CP030B
30A, 50 MHz High Sensitivity Current Probe - AC/DC, 30 A rms, 50 A Peak Pulse, 1.5 meter cable
CP030B-3M
30 A, 10 MHz Current Probe - AC/DC, 30 A rms, 50 A Peak Pulse, 3 meter cable
CP030
30A, 50 MHz Current Probe - AC/DC, 30 A rms, 50 A Peak Pulse, 1.5 meter cable Limited Availability
CP030-3M
30 A, 10 MHz Current Probe - AC/DC, 30 A rms, 50 A Peak Pulse, 3 meter cable Limited Availability
CP030A
30A, 50 MHz High Sensitivity Current Probe - AC/DC, 30 A rms, 50 A Peak Pulse, 1.5 meter cable Limited Availability
CP031
30A, 100 MHz Current Probe - AC/DC, 30 A rms, 50 A Peak Pulse, 1.5 meter cable
CP031A
30A, 100 MHz High Sensitivity Current Probe - AC/DC, 30 A rms, 50 A Peak Pulse, 1.5 meter cable
CP150B
150 A, 10 MHz Current Probe - AC/DC, 150 A rms, 500 A Peak Pulse, 2 meter cable
CP150B-6M
150 A, 5 MHz Current Probe - AC/DC, 150 A rms, 500 A Peak Pulse, 6 meter cable
CP150
150 A, 10 MHz Current Probe - AC/DC, 150 A rms, 500 A Peak Pulse, 2 meter cable Limited Availability
CP150-6M
150 A, 5 MHz Current Probe - AC/DC, 150 A rms, 500 A Peak Pulse, 6 meter cable Limited Availability
CP500
500 A, 2 MHz Current Probe - AC/DC, 500 A rms, 700 A Peak Pulse, 6 meter cable
DCS025
Deskew Calibration Source for Teledyne LeCroy current probes

Differential Probes (<= 1.5 GHz)

AP033
500 MHz Differential Probe
ZD1000
1 GHz, 1.0 pF Active Differential Probe, ±8 V
ZD1500
1.5 GHz, 1.0 pF Active Differential Probe, ±8 V
ZD500
500 MHz, 1.0 pF Active Differential Probe, ±8 V

High Voltage Differential Probes

HVD3102A
1kV, 25 MHz High Voltage Differential Probe with Auto Zero Disconnect
HVD3102A-NOACC
1kV, 25 MHz High Voltage Differential Probe without tip Accessories and with Auto Zero Disconnect
HVD3106A
1kV, 120 MHz High Voltage Differential Probe with Auto Zero Disconnect
HVD3106A-NOACC
1kV, 120 MHz High Voltage Differential Probe without tip Accessories and with Auto Zero Disconnect
HVD3106A-6M
1kV, 80 MHz High Voltage Differential Probe with 6m cable and Auto Zero Disconnect
HVD3206A
2kV, 120 MHz High Voltage Differential Probe with Auto Zero Disconnect
HVD3206A-6M
2kV, 80 MHz High Voltage Differential Probe with 6m cable and Auto Zero Disconnect
HVD3220
2kV, 400 MHz High Voltage Differential Probe
HVD3605A
6kV, 100 MHz High Voltage Differential Probe with Auto Zero Disconnect
AP031
700 V, 25 MHz High-Voltage Differential Probe (÷10, ÷100) Limited Availability

High Voltage Probes

HVP120
6kV High Voltage Passive Probe, 400 MHz
PPE6KV-A
6kV High Voltage Passive Probe, 500 MHz

Passive Probes

PP019-1
250 MHz Passive Probe for WaveSurfer 3000, 10:1, 10 MOhm
PP026-1
500 MHz Passive Probe, 5mm, 10:1, 10 MOhm

60 V Common Mode Probes

DL02-HCM
250 MHz 60 V Common Mode Differential Probe. Includes standard set of leads and tips.
DL05-HCM
500 MHz 60 V Common Mode Differential Probe. Includes standard set of leads and tips.
DL10-HCM
1 GHz 60 V Common Mode Differential Probe. Includes standard set of leads and tips.
DL-HCM-HiTemp
DL-HCM series high-temperature solder-in tip, 30 MHz bandwidth, 1 meter length.
DL-HCM-Acc-Kit
DL-HCM series accessories kit with probe holder, micro IC grabbers (Qty 2.), and Y-banana adaptor.
